Xtreme Performance Geometry
Vortex states that the XP design is intended to provide as much as three to five times more tool life than standard compression geometry.
Vortex Tool Xtreme Performance 2-Flute Compression Spiral Router Bit with Chipbreakers, 1/2" × 1"
CA$224.25
In stock
SKU
3435XP
Product Type
Two-flute Xtreme Performance compression spiral router bit with chipbreakers
Series
Vortex Tool Series 3400XP
Cutting Geometry
Two-flute compression · Chipbreakers · Right-hand rotation
Cutting Diameter
1/2 in
Cutting Edge Length
1 in
Shank / Overall Length
1/2 in shank · 3 in overall length
Upcut Length
0.550 in
Cutting Material
Solid carbide
Material Focus
Solid wood and plywood
Two-Flute Xtreme Performance
Compression Spiral
Series 3400XP
A solid-carbide Vortex Tool Series 3400XP two-flute Xtreme Performance compression spiral router bit with chipbreakers for solid-wood and plywood routing. The verified 3435XP configuration combines a 1/2-inch cutting diameter, 1-inch cutting-edge length, 1/2-inch shank, 3-inch overall length, and 0.550-inch upcut section.
1/2 inCutting Diameter
1 inCutting Edge Length
0.550 inUpcut Length
3 inOverall Length
XP Compression Chipbreaker
This Series 3400XP solid-carbide tool combines two-flute compression geometry with chipbreakers and Vortex’s Xtreme Performance design. Vortex states that the XP geometry is designed to provide as much as three to five times more tool life than standard compression geometry, while the chipbreaker design supports free-cutting action in solid wood and plywood.
Solid CarbideXtreme PerformanceChipbreakersSKU 3435XP
Designed for compatible CNC routers and routing systems using standard right-hand rotation and a precision 1/2-inch collet or holder. Position the 0.550-inch upcut section correctly within the material so the compression transition performs as intended.
Main Product Description
The Vortex Tool 3435XP is a Series 3400XP two-flute Xtreme Performance compression spiral router bit with chipbreakers. Its compression geometry combines upcut and downcut flute sections to help control edge quality on both faces of a properly positioned through cut.
Vortex states that its XP geometry is specifically designed to provide as much as three to five times more tool life than standard compression geometry. The manufacturer also identifies the chipbreaker design for free-cutting action in solid wood and plywood materials.
The verified 3435XP dimensions are a 1/2-inch cutting-edge diameter, 1-inch cutting-edge length, 1/2-inch shank diameter, 3-inch overall length, and 0.550-inch upcut section. Correct collet condition, shank engagement, tool projection, transition depth, workholding, feed, spindle speed, and chip evacuation remain essential to production performance.
Technical Specifications
Series 3400XP · SKU 3435XP
- Vortex Tool
- Two-Flute Xtreme Performance Compression Spiral Router Bit with Chipbreakers
- 3435XP
- 3400XP — Xtreme Performance
- 1/2 in
- 1 in
- 1/2 in
- 3 in
- 2
- Right-Hand
- Solid Carbide
- Cutting Geometry: Compression with Chipbreakers · Upcut Length: 0.550 in
- Recommended Materials: Solid Wood and Plywood · Primary Application: Xtreme Performance Compression Routing with Chipbreaker Cutting Action
- Designed for compatible CNC routers and routing systems using standard right-hand rotation and a precision 1/2-inch collet or holder. Position the 0.550-inch upcut section correctly within the material so the compression transition performs as intended.
Best Fit Applications
Solid-Wood Profile Routing
Plywood Through Cuts
XP Production Routing
Chipbreaker Compression Cuts
Clean Top-and-Bottom Edges
Product Highlights
Two-Flute Chipbreaker Compression
The chipbreaker design supports free-cutting action in solid wood and plywood while opposing flute directions help control both panel faces.
Verified 1/2-Inch Configuration
A 1/2-inch diameter, 1-inch cutting length, 1/2-inch shank, 3-inch overall length, and 0.550-inch upcut section define the exact 3435XP format.
Compatibility & Installation Notes
Use a clean, undamaged precision 1/2-inch collet or compatible holder with adequate shank engagement and safe tool projection. Confirm standard right-hand spindle rotation. Position the 0.550-inch upcut section so the compression transition remains within the workpiece during the cut; incorrect depth can prevent the opposing flute sections from protecting both panel faces. Verify material thickness, programmed depth, entry strategy, workholding, spindle condition, feed rate, spindle speed, chip evacuation, and machine clearance before production.
Xtreme Performance Compression
Vortex Tool 3435XP combines solid-carbide construction, two-flute Xtreme Performance compression geometry, chipbreakers, and a 0.550-inch upcut section in a 1/2-inch-diameter configuration for solid-wood and plywood routing.
Vortex’s XP design targets extended service life compared with standard compression geometry. Correct collet fit, transition depth, tool projection, cutting parameters, workholding, and chip evacuation remain essential to the result.
