Vortex Tool Series 3100XP Two-Flute Xtreme Performance Compression Spiral Router Bit – 3/8 in Diameter x 1-1/8 in Cutting Length
Xtreme Performance
Compression Spiral
A Vortex Tool Series 3100XP two-flute solid-carbide compression spiral with a 3/8-inch cutting diameter, 1-1/8-inch cutting-edge length, 0.500-inch upcut length, 3/8-inch shank, and 3-inch overall length. The XP geometry is engineered for demanding melamine, high-pressure laminated particle board, and MDF routing where clean edges and extended service life are priorities.
Main Product Description
The Vortex Tool 3130XP is part of the Series 3100XP two-flute “Xtreme Performance” compression-spiral range. Its compression geometry combines upcut and downcut flute sections so the material is directed toward the centre of the panel, helping prevent chipping or fuzzing at both the top and bottom edges of a through cut.
Vortex developed the XP series for melamine, high-pressure laminated particle board, and MDF applications where standard compression geometry may deliver insufficient tool life. The manufacturer positions this geometry for longer service in these demanding panel materials while preserving the clean two-sided edge control expected from a compression spiral.
The verified 3130XP configuration uses a 3/8-inch cutting-edge diameter, 1-1/8-inch cutting-edge length, 3/8-inch shank, 3-inch overall length, 0.500-inch upcut section, and two-flute right-hand rotation. Correct collet condition, spindle runout, tool projection, feed rate, RPM, workholding, and chip evacuation remain essential to finish quality and service life.
Best Fit Applications
Product Highlights
Xtreme Performance Geometry
Series 3100XP geometry is manufactured for demanding melamine, HPL particle board, and MDF routing where tool life is a primary concern.
Two-Sided Edge Control
Combined upcut and downcut flute sections compress the cut toward the panel centre to support clean edges on both faces.
Standard 0.500-Inch Upcut
The 3/8-inch format pairs a 1-1/8-inch cutting length with a 0.500-inch upcut section, 3/8-inch shank, and 3-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 3/8-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cut depth, panel support, workholding, and chip evacuation before use. Program the cut so the 0.500-inch upcut section and the compression transition are positioned correctly within the workpiece to support the intended top- and bottom-edge finish.
XP Life with Compression Finish
Vortex Tool 3130XP combines Series 3100XP two-flute Xtreme Performance compression geometry with a verified 3/8-inch cutting diameter, 1-1/8-inch cutting length, 3/8-inch shank, 0.500-inch upcut, and 3-inch overall length.
The result is a solid-carbide routing tool engineered for demanding laminated panel and MDF applications where clean edges on both faces and extended service life are important production goals.
