Left-Hand Rotation
Manufactured specifically for compatible counterclockwise spindle rotation and left-hand routing applications.
Vortex Tool 1/2" “The Viper” 2-Flute Left-Hand Mortise Compression Spiral Router Bit
CA$204.20
In stock
SKU
3189L
Product Type
Two-Flute Left-Hand Mortise Compression Spiral Router Bit
Series
Vortex Tool Series 3100M “The Viper”
Cutting Geometry
Upcut and downcut mortise-compression geometry · Left-hand rotation
Cutting Diameter
1/2 in
Cutting Edge Length
1 in
Upcut Length
0.250 in mortise upcut
Shank / Overall Length
1/2 in shank · 3 in overall length
Cutting Material
Solid Carbide
Application
Left-hand mortise grooves and compatible material 5/8 in thick or less
Left-Hand Viper
Mortise Compression
Series 3100M
A Vortex Tool Series 3100M “The Viper” two-flute solid-carbide left-hand mortise compression spiral with a 1/2-inch cutting diameter, 1-inch cutting-edge length, 0.250-inch upcut length, 1/2-inch shank, and 3-inch overall length. The mortise geometry is designed for groove cutting and compatible materials 5/8 inch thick or less while helping protect both faces of the workpiece.
1/2 inCutting Diameter
1 inCutting Edge Length
0.250 inMortise Upcut
Left-HandRotation
2-Flute LH Mortise Compression
This Series 3100M Viper router bit combines upcut and downcut flute sections with a 1/4-inch mortise upcut and left-hand rotation to help prevent chipping or fuzzing on the top and bottom of compatible thin panel materials and mortise grooves.
Solid CarbideThe ViperLeft-HandSKU 3189L
Designed for compatible CNC routers and routing machines configured for counterclockwise, left-hand tool rotation and using a correctly sized 1/2-inch collet or toolholder. Confirm spindle direction, tool projection, workpiece thickness, groove depth, RPM, feed, workholding, and chip evacuation before production use.
Main Product Description
The Vortex Tool 3189L belongs to the Series 3100M “The Viper” two-flute mortise-compression range. Its upcut and downcut flute sections compress the cut toward the centre of the workpiece, helping reduce chipping or fuzzing on both the top and bottom edges.
Series 3100M is designed for mortise cuts or for cutting material 5/8 inch thick or less. Vortex defines mortise cuts as grooves typically cut to a depth equal to or slightly less than the tool diameter, and the 0.250-inch upcut section is configured for this thin-material and groove-cutting role.
The verified 3189L configuration uses a 1/2-inch cutting-edge diameter, 1-inch cutting-edge length, 1/2-inch shank, 3-inch overall length, 0.250-inch upcut section, two flutes, and left-hand rotation. The machine spindle and programmed toolpath must be compatible with counterclockwise left-hand tooling before installation.
Technical Specifications
Series 3100M · SKU 3189L
- Vortex Tool
- Two-Flute Left-Hand Mortise Compression Spiral Router Bit
- 3189L
- 3100M — “The Viper”
- 1/2 in
- 1 in
- 1/2 in
- 3 in
- 2
- Left-Hand / Counterclockwise
- Solid Carbide
- Upcut Length: 0.250 in · Upcut Configuration: Mortise · Cutting Geometry: Upcut / Downcut Compression · Material Thickness Range: 5/8 in or Less
- Left-Hand CNC Routing · Mortise Groove Cutting · Thin Laminated Panels
- Designed for compatible CNC routers and routing machines configured for counterclockwise, left-hand tool rotation and using a correctly sized 1/2-inch collet or toolholder. Confirm spindle direction, tool projection, workpiece thickness, groove depth, RPM, feed, workholding, and chip evacuation before production use.
Best Fit Applications
Left-Hand CNC Routing
Mortise Groove Cutting
Thin Laminated Panels
Double-Sided Laminates
Painted or Vinyl-Faced Board
Product Highlights
Mortise-Specific Geometry
The 0.250-inch upcut section is designed for groove cutting and compatible workpieces 5/8 inch thick or less.
Two-Sided Edge Control
Combined upcut and downcut flute sections compress the cut toward the workpiece centre to support clean edges on both faces.
Compatibility & Installation Notes
Use only in machinery and toolpaths configured for left-hand, counterclockwise cutting rotation. Confirm a clean, undamaged 1/2-inch collet or compatible holder, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, groove depth, panel support, workholding, and chip evacuation before use. Program the toolpath so the 0.250-inch upcut section and compression transition are positioned correctly within the workpiece. For mortise work, groove depth is typically equal to or slightly less than the 1/2-inch tool diameter.
Left-Hand Mortise Control
Vortex Tool 3189L combines Series 3100M Viper two-flute left-hand mortise-compression geometry with a verified 1/2-inch cutting diameter, 1-inch cutting length, 0.250-inch upcut, 1/2-inch shank, and 3-inch overall length.
The solid-carbide design is intended for compatible counterclockwise mortise-groove and thin-panel routing where clean top and bottom edges are important production goals.
