Viper Compression Geometry
Combined upcut and downcut flute sections compress the cut toward the panel centre to support clean edges on both faces.
Vortex Tool 3/8" × 1-1/8" Series “The Viper” 2-Flute Compression Spiral Router Bit
CA$119.25
In stock
SKU
3130
Product Type
Two-Flute Compression Spiral Router Bit
Series
Vortex Tool Series 3100 “The Viper”
Cutting Geometry
Upcut and downcut compression geometry · Right-hand rotation
Cutting Diameter
3/8 in
Cutting Edge Length
1-1/8 in
Upcut Length
0.500 in
Shank / Overall Length
3/8 in shank · 3 in overall length
Cutting Material
Solid Carbide
Application
Clean top and bottom edges in compatible double-sided laminated panels
The Viper
Compression Spiral
Series 3100
A Vortex Tool Series 3100 two-flute solid-carbide compression spiral with a 3/8-inch cutting diameter, 1-1/8-inch cutting-edge length, 0.500-inch upcut length, 3/8-inch shank, and 3-inch overall length. Its combined upcut and downcut geometry is designed to reduce chipping and fuzzing on both faces of compatible panel materials.
3/8 inCutting Diameter
1-1/8 inCutting Edge Length
0.500 inUpcut Length
2Flutes
2-Flute Compression Spiral
This Series 3100 “The Viper” router bit combines upcut and downcut flute sections to support clean top and bottom edges in compatible double-sided laminated panels and other suitable routing materials.
Solid CarbideCompressionRight-HandSKU 3130
Designed for compatible CNC routers and routing machines using a correctly sized 3/8-inch collet or toolholder. Confirm spindle rotation, tool projection, panel thickness, cut depth, RPM, feed, workholding, and chip evacuation before production use.
Main Product Description
The Vortex Tool 3130 is part of the Series 3100 “The Viper” two-flute compression-spiral range. Compression geometry combines upcut and downcut flute sections so the material is directed toward the centre of the panel, helping reduce chipping or fuzzing at both the top and bottom edges of a through cut.
Vortex identifies the Series 3100 for double-sided laminated materials including melamine, vinyl-laminated panels, high-pressure laminate, and painted board. The series is not recommended for material thinner than 5/8 inch; the 0.500-inch upcut section must be considered when matching the bit to panel thickness and programmed cut depth.
The verified 3130 configuration uses a 3/8-inch cutting-edge diameter, 1-1/8-inch cutting-edge length, 3/8-inch shank, 3-inch overall length, and two-flute right-hand compression geometry. Correct collet condition, spindle runout, tool projection, feed rate, RPM, workholding, and chip evacuation remain essential to finish quality and tool life.
Technical Specifications
Series 3100 · SKU 3130
- Vortex Tool
- Two-Flute Compression Spiral Router Bit
- 3130
- 3100 — “The Viper”
- 3/8 in
- 1-1/8 in
- 3/8 in
- 3 in
- 2
- Right-Hand
- Solid Carbide
- Upcut Length: 0.500 in · Cutting Geometry: Upcut / Downcut Compression · Series Thickness Guidance: Not Recommended Below 5/8 in
- Double-Sided Melamine Panels · High-Pressure Laminate Panels · Vinyl-Laminated Panels
- Designed for compatible CNC routers and routing machines using a correctly sized 3/8-inch collet or toolholder. Confirm spindle rotation, tool projection, panel thickness, cut depth, RPM, feed, workholding, and chip evacuation before production use.
Best Fit Applications
Double-Sided Melamine Panels
High-Pressure Laminate Panels
Vinyl-Laminated Panels
Painted Board Routing
Natural Wood with Edge Fuzzing Concerns
Product Highlights
Double-Sided Panel Focus
Series 3100 is intended for compatible laminated panel products where top- and bottom-edge quality are both important.
Verified 3/8-Inch Format
The 3/8-inch cutting diameter and shank are paired with a 1-1/8-inch cutting length, 0.500-inch upcut, and 3-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 3/8-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cut depth, panel support, workholding, and chip evacuation before use. Match the programmed cut depth and material thickness to the 0.500-inch upcut section so the compression transition supports the intended top- and bottom-edge finish. Vortex does not recommend this Series 3100 geometry for material thinner than 5/8 inch.
Clean Edges on Both Faces
Vortex Tool 3130 combines Series 3100 “The Viper” two-flute compression geometry with a verified 3/8-inch cutting diameter, 1-1/8-inch cutting length, 3/8-inch shank, 0.500-inch upcut, and 3-inch overall length for compatible double-sided panel routing.
Correct spindle condition, collet fit, panel thickness, tool projection, feed, RPM, cut depth, chip evacuation, and workholding are essential to achieving the intended edge quality and service life.
