Two-Sided Edge Control
Opposing upcut and downcut flute sections compress the panel faces toward the centre to help reduce chipping and fuzzing on both surfaces.
Vortex Tool 1/4" × 7/8" The Viper 2-Flute Compression Spiral Router Bit
CA$95.50
In stock
SKU
3110
Product Type
Two-Flute Compression Spiral Router Bit
Series
Vortex Tool Series 3100 · The Viper
Cutting Geometry
Upcut and downcut compression geometry · Right-hand rotation
Cutting Diameter
1/4 in
Cutting Edge Length
7/8 in
Shank / Overall Length
1/4 in shank · 3 in overall length
Upcut Length
1/4 in
Cutting Material
Solid Carbide
Application
Double-sided laminated panels 5/8 in thick or greater
Two-Flute Compression
The Viper
Series 3100
A Vortex Tool Series 3100 solid-carbide two-flute compression spiral router bit with a 1/4-inch cutting diameter, 7/8-inch cutting-edge length, 1/4-inch shank, 3-inch overall length, and 1/4-inch upcut length. The Viper combines upcut and downcut flute sections to support clean top and bottom edges in compatible double-sided laminated materials.
1/4 inCutting Diameter
7/8 inCutting Edge Length
1/4 inUpcut Length
2Compression Flutes
2-Flute Viper Compression
This Series 3100 tool uses opposing upcut and downcut spiral sections to compress the workpiece faces toward the centre of the panel, helping reduce chipping or fuzzing on both surfaces.
Solid CarbideCompressionThe ViperSKU 3110
Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, adequate shank engagement, minimum practical projection, secure workholding, cut depth, RPM, feed, and chip evacuation before production use.
Main Product Description
The Vortex Tool 3110 belongs to Series 3100, officially named “The Viper” two-flute compression spiral range. Compression geometry combines an upcut section near the tool tip with a downcut section above it, directing cutting forces toward the centre of the material to support clean top and bottom edges.
Vortex specifies this series for double-sided laminates including melamine, vinyl-faced panels, high-pressure laminates, and painted board. The manufacturer does not recommend the standard Series 3100 geometry for material thinner than 5/8 inch.
The verified 3110 configuration uses a 1/4-inch cutting-edge diameter, 7/8-inch cutting-edge length, 1/4-inch shank, 3-inch overall length, and 1/4-inch upcut length. Correct collet condition, low spindle runout, suitable cut depth, secure workholding, and appropriate feed and RPM are essential to stable compression routing.
Technical Specifications
Series 3100 · SKU 3110
- Vortex Tool
- Two-Flute Compression Spiral Router Bit
- 3110
- 3100 — “The Viper”
- 1/4 in
- 7/8 in
- 1/4 in
- 3 in
- 2
- Right-Hand
- Solid Carbide
- Upcut Length: 1/4 in · Cutting Geometry: Upcut / Downcut Compression · Series Thickness Note: Not Recommended Below 5/8 in
- Double-Sided Melamine Panels · High-Pressure Laminates · Vinyl-Faced Panel Routing
- Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, adequate shank engagement, minimum practical projection, secure workholding, cut depth, RPM, feed, and chip evacuation before production use.
Best Fit Applications
Double-Sided Melamine Panels
High-Pressure Laminates
Vinyl-Faced Panel Routing
Painted Board Profiling
Clean Top and Bottom Edges
Product Highlights
The Viper Geometry
Vortex developed the Series 3100 flute form for strong cutting performance and extended useful sharpening life in compatible laminated panel applications.
Verified 1/4-Inch Format
The 1/4-inch cutting diameter and shank are paired with a 7/8-inch cutting length, 3-inch OAL, and 1/4-inch upcut section.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible toolholder, correct right-hand spindle rotation, adequate shank engagement, minimum practical projection, machine RPM limits, feed rate, chip evacuation, workholding, and cut depth before use. The standard Series 3100 geometry is not recommended for materials thinner than 5/8 inch; ensure the toolpath engages the compression sections appropriately for the panel thickness.
Two-Sided Laminate Finish
Vortex Tool 3110 combines The Viper two-flute compression geometry with a verified 1/4-inch diameter, 7/8-inch cutting length, and 1/4-inch upcut section for compatible double-sided laminated panel routing.
Correct 1/4-inch collet fit, low spindle runout, appropriate cut depth, secure workholding, suitable feed and RPM, and effective chip evacuation are essential to stable cutting performance.
