Pass-By Clearance
The reduced diameter between the cutting edge and shank creates clearance for deep-pocket mortising and stepped cuts through thicker workpieces.
Vortex Tool 5/8" 3-Flute Roughing Pass-By Mortise Upcut Router Bit
CA$673.30
In stock
SKU
2377R
Product Type
Three-Flute Roughing Pass-By Mortise Upcut Router Bit
Series
Vortex Tool Series 2300
Cutting Geometry
Pass-by deep-pocket upcut · Three roughing flutes · Right-hand rotation
Cutting Diameter
5/8 in
Cutting Edge Length
2 in
Shank / Overall Length
5/8 in shank · 6 in overall length
Depth of Cut
4-1/2 in
Cutting Material
Solid Carbide
Application
Deep-pocket mortising and step cutting through thick materials
Two-Flute Pass-By
Mortise Upcut Finisher
Series 2300
A Vortex Tool Series 2300 solid-carbide roughing pass-by router bit with a 5/8-inch cutting diameter, 2-inch cutting-edge length, 5/8-inch shank, 6-inch overall length, and 4-1/2-inch depth-of-cut capacity. Its reduced-diameter pass-by section supports deep-pocket mortise cuts and step cutting through thick materials.
5/8 inCutting Diameter
2 inCutting Edge Length
4-1/2 inDepth of Cut
3Finish Flutes
3-Flute Pass-By Rougher
This Series 2300 upcut tool combines three roughing flutes with a reduced diameter between the cutting edge and shank, allowing the bit to pass deeper into compatible workpieces for mortising, deep-pocket routing, and stepped cuts.
Solid CarbideUpcutRoughing GeometrySKU 2377R
Designed for compatible CNC routers and routing machines using a clean, correctly sized 5/8-inch collet or toolholder. Confirm right-hand spindle rotation, sufficient shank engagement, minimum practical projection, secure workholding, RPM, feed, chip evacuation, and step-cut strategy before production use.
Main Product Description
The Vortex Tool 2377R belongs to the Series 2300 pass-by/deep-pocket mortise upcut range and uses the catalog's three-flute roughing geometry. Pass-by tooling uses a long overall length and a reduced diameter between the end of the cutting edge and the shank, creating clearance for deeper routing operations than a conventional full-diameter body would permit.
This exact configuration uses three roughing flutes with upcut spiral geometry. The upward chip path supports chip removal from deep pockets and mortises, while the roughing profile is intended for efficient stock removal before any separate finishing pass required by the application.
The verified 2377R dimensions are a 5/8-inch cutting-edge diameter, 2-inch cutting-edge length, 5/8-inch shank, 6-inch overall length, and 4-1/2-inch depth of cut. Correct collet condition, low spindle runout, controlled tool projection, secure workholding, and suitable stepped toolpaths are essential for this extended-reach finishing tool.
Technical Specifications
Series 2300 · SKU 2377R
- Vortex Tool
- Three-Flute Roughing Pass-By Mortise Upcut Router Bit
- 2377R
- 2300 — Pass-By / Deep-Pocket Mortise Upcut
- 5/8 in
- 2 in
- 5/8 in
- 6 in
- 3
- Right-Hand
- Solid Carbide
- Depth of Cut: 4-1/2 in · Flute Geometry: Rough · Cutting Direction: Upcut
- Deep-Pocket Mortise Routing · Step Cutting Through Thick Material · Narrow Deep Slot Routing
- Designed for compatible CNC routers and routing machines using a clean, correctly sized 5/8-inch collet or toolholder. Confirm right-hand spindle rotation, sufficient shank engagement, minimum practical projection, secure workholding, RPM, feed, chip evacuation, and step-cut strategy before production use.
Best Fit Applications
Deep-Pocket Mortise Routing
Step Cutting Through Thick Material
Narrow Deep Slot Routing
Extended-Reach CNC Profiling
Three-Flute Roughing Cuts
Product Highlights
Three-Flute Roughing Geometry
Three roughing flutes provide the verified Series 2300 cutting configuration for deep routing operations where efficient stock removal and chip clearance are the priority.
Compact Extended Reach
The 5/8-inch cutting diameter and 2-inch cutting length are paired with a 5/8-inch shank, 6-inch OAL, and 4-1/2-inch depth of cut.
Compatibility & Installation Notes
Confirm a clean, undamaged 5/8-inch collet or compatible toolholder, correct right-hand spindle rotation, adequate shank engagement, minimum practical tool projection, machine RPM limits, feed rate, step depth, chip evacuation, and workholding before use. Upcut geometry can lift the workpiece, while the 6-inch overall length and 4-1/2-inch depth-of-cut capacity make runout control, secure workholding, and suitable step-downs especially important.
Deep Mortise Reach
Vortex Tool 2377R combines a reduced-diameter pass-by body, three-flute roughing geometry, and upward chip evacuation for compatible deep-pocket mortise and step-cutting operations.
Correct 5/8-inch collet fit, low spindle runout, minimal practical projection, secure workholding, suitable stepped toolpaths, and effective chip evacuation are essential to stable performance.
