Verified Left-Hand Variant
The L suffix identifies the official left-hand rotation version and must be matched to the machine spindle direction.
Vortex Tool Series 1300 Left-Hand Two-Flute Downcut Finishing Spiral Router Bit, 1/2 in × 1-3/4 in
CA$169.75
In stock
SKU
1360L
Product Type
Two-flute downcut finishing spiral router bit
Series
Vortex Tool Series 1300
Cutting Geometry
Two-flute downcut finishing spiral
Rotation
Left hand
Cutting Diameter
1/2 in
Cutting Edge Length
1-3/4 in
Shank / Overall Length
1/2 in shank · 3-1/2 in overall length
Cutting Material
Solid carbide
Applications
Clean top-edge dado,groove,through-cut and nested CNC routing
Left-Hand
Downcut Finisher
Series 1300
A solid-carbide, two-flute downcut finishing spiral configured for left-hand rotation. SKU 1360L combines a 1/2-inch cutting diameter, 1-3/4-inch cutting length, 1/2-inch shank, and 3-1/2-inch overall length for clean top-edge routing and downward chip flow.
1/2 inCutting Diameter
1-3/4 inCutting Edge Length
Two FluteFinishing Geometry
Left HandRotation
Downcut Finishing Spiral
Series 1300 uses two-flute downcut finishing geometry to produce a clean top edge while directing chips downward and helping hold properly secured parts against a table or pod.
Solid CarbideTwo FluteDowncutLeft-Hand Rotation
Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or holder and a spindle configured for the verified left-hand cutting rotation.
Main Product Description
The Vortex Tool 1360L is the left-hand version of the 1/2-inch Series 1300 two-flute downcut finishing spiral. Its down-shearing action is intended for operations where a clean top edge is the priority, including dado cuts, groove cuts, and through-cuts where bottom-edge quality is less important.
The downcut spiral directs chips toward the work surface while helping maintain part contact with a properly supported table or pod. In nested routing, the chip-packed toolpath can also help preserve vacuum around the cut when the material and machining setup are suitable.
The verified configuration uses a 1/2-inch cutting-edge diameter, 1-3/4-inch cutting-edge length, 1/2-inch shank, 3-1/2-inch overall length, two finishing flutes, and left-hand rotation. The spindle direction, collet condition, tool projection, workholding, entry method, feed, speed, and chip evacuation must all match the application.
Technical Specifications
Left-Hand Downcut Finisher · SKU 1360L
- Vortex Tool
- Two-Flute Downcut Finishing Spiral Router Bit
- 1360L
- Series 1300
- 1/2 in
- 1-3/4 in
- 1/2 in
- 3-1/2 in
- 2
- Left Hand
- Solid Carbide
- Cutting Geometry: Downcut Finishing Spiral · Cut Behaviour: Clean Top Edge with Downward Chip Flow
- Primary Operations: Dado, Groove, Through-Cut, and Nested Routing
- Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or holder and a spindle configured for the verified left-hand cutting rotation.
Best Fit Applications
Clean Top-Edge Routing
Dado Cutting
Groove Cutting
Nested CNC Routing
Left-Hand Spindle Systems
Product Highlights
Downcut Edge Control
Down-shearing geometry prioritizes a clean top edge while directing chips downward through the routed path.
Extended 1-3/4-Inch Cut
The 1/2-inch cutting diameter is paired with a 1-3/4-inch cutting length, 1/2-inch shank, and 3-1/2-inch OAL.
Compatibility & Installation Notes
This is a left-hand rotation tool. Confirm that the spindle, holder, collet, programmed rotation, and toolpath are compatible with the verified left-hand cutting rotation before operation. Use a clean, undamaged precision 1/2-inch collet or holder with adequate shank engagement and minimum practical projection. Verify clearance for the 1-3/4-inch cutting length and 3-1/2-inch overall length, and secure the workpiece against the downward chip load. Do not plunge straight down with this downcut tool; use an appropriate ramp, lead-in, predrilled entry, or other machine-approved entry strategy. Confirm feed, spindle speed, chip evacuation, vacuum support, and cut direction before production.
Left-Hand Downcut Control for Clean Top Edges
Vortex Tool 1360L combines solid-carbide construction, two-flute finishing geometry, downward chip flow, and verified left-hand rotation in a 1/2-inch cutting configuration.
Correct spindle direction, collet fit, tool projection, entry method, workholding, vacuum support, cutting parameters, and chip management are essential for controlled dado, groove, through-cut, and nested-routing operations.
