Clean Top-Edge Finish
The down-shearing flute direction is designed to support a clean top edge in compatible dados, grooves, profiles, and through-routing operations.
Vortex Tool 3/8" × 1-1/4" 2-Flute Downcut Finishing Spiral Router Bit
CA$85.85
In stock
SKU
1340
Product Type
Two-Flute Downcut Finishing Spiral Router Bit
Series
Vortex Tool Series 1300
Cutting Geometry
Two-flute downcut finishing geometry · Right-hand rotation
Cutting Diameter
3/8 in
Cutting Edge Length
1-1/4 in
Shank / Overall Length
3/8 in shank · 3 in overall length
Cutting Material
Solid Carbide
Application
Clean top-edge CNC routing with downward chip flow and improved workpiece hold-down
Entry Method
Use ramped or pre-drilled entry · Do not plunge straight down
Two-Flute Downcut
Finishing Spiral
Series 1300
A Vortex Tool Series 1300 two-flute solid-carbide downcut finishing spiral with a 3/8-inch cutting diameter, 1-1/4-inch cutting-edge length, 3/8-inch shank, and 3-inch overall length. Its down-shearing geometry is designed to support a clean top edge, direct chips downward, and help hold compatible workpieces against the table or pod.
3/8 inCutting Diameter
1-1/4 inCutting Edge Length
3/8 inShank Diameter
2Flutes
2-Flute Downcut Finisher
This Series 1300 solid-carbide finishing tool uses two helical downcut flutes to produce a clean top edge in compatible dado, groove, profile, and through-routing operations while directing chips downward.
Solid CarbideDowncut2 FlutesSKU 1340
Designed for compatible CNC routers and routing machines using a clean, correctly sized 3/8-inch collet or toolholder. Confirm right-hand spindle rotation, shank engagement, tool projection, ramped entry, RPM, feed, workholding, and material suitability before production use.
Main Product Description
The Vortex Tool 1340 is the standard right-hand member of the Series 1300 two-flute downcut finishing spiral range. Vortex lists a separate left-hand-rotation counterpart. Vortex positions this geometry for operations where the down-shearing effect is preferred and top-edge finish is more important than the bottom edge of the cut.
The downcut spiral directs chip flow downward while helping hold parts against a table or pod. In nested cutting, the routed path can remain packed with chips, which may help preserve vacuum around the workpiece when the toolpath, dust collection, and machine setup are correctly matched.
The verified 1340 configuration uses a 3/8-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 3/8-inch shank, and 3-inch overall length. Correct collet condition, spindle runout, tool projection, ramped entry, feed rate, RPM, cut depth, chip evacuation, and workholding remain essential to finish quality and tool life.
Technical Specifications
Series 1300 · SKU 1340
- Vortex Tool
- Two-Flute Downcut Finishing Spiral Router Bit
- 1340
- 1300 — Two-Flute Downcut Finishing Spirals
- 3/8 in
- 1-1/4 in
- 3/8 in
- 3 in
- 2
- Right-Hand
- Solid Carbide
- Cutting Direction: Downcut · Primary Cut Behaviour: Clean Top Edge with Downward Chip Flow
- Clean Top-Edge Routing · Dado & Groove Cutting · Nested CNC Routing
- Designed for compatible CNC routers and routing machines using a clean, correctly sized 3/8-inch collet or toolholder. Confirm right-hand spindle rotation, shank engagement, tool projection, ramped entry, RPM, feed, workholding, and material suitability before production use.
Best Fit Applications
Clean Top-Edge Routing
Dado & Groove Cutting
Nested CNC Routing
Pod & Table Workholding
Compatible Through Cuts
Product Highlights
Downward Chip Flow
The downcut geometry directs chips and cutting pressure downward, helping hold compatible parts against the table or pod during routing.
Compact Finishing Configuration
The 3/8-inch cutting diameter and 1-1/4-inch cutting length are paired with a matching 3/8-inch shank and 3-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 3/8-inch collet or compatible toolholder, correct right-hand spindle rotation, adequate shank engagement, minimum practical tool projection, machine RPM limits, feed rate, cut depth, chip evacuation, workholding, and material support before use. Do not plunge straight down with downcut tooling; use a suitable ramped or pre-drilled entry strategy because straight plunging can cause overheating, fire, or tool breakage.
Clean Top-Edge Downcut Finishing
Vortex Tool 1340 combines two-flute downcut finishing geometry with a verified 3/8-inch cutting diameter, 1-1/4-inch cutting length, 3/8-inch shank, and 3-inch overall length for compatible precision CNC routing operations.
Correct collet fit, spindle condition, minimal tool projection, ramped entry, feed, RPM, cut depth, chip management, workholding, and material selection are essential to achieving the intended clean top edge and stable routing performance.
