Working geometry
Use the cutter for the final pass that establishes the finished edge.
Vortex 1210 – 2-Flute Upcut Finishing Spiral Router Bit – 1/8 in Diameter
CA$37.35
In stock
SKU
1210
Product Type
2-Flute Upcut Finishing Spiral Router Bit
Tool Material
Solid Carbide
Cutting Diameter
1/8 in
Cutting Length
1/2 in
Shank Diameter
1/4 in
Overall Length
2 in
Flutes
2
Cut Direction
Upcut
Rotation
Right Hand
2-Flute Upcut Finishing Spiral Router Bit
Vortex
1210
Designed to finish routed edges and contours.
1/8 inCutting Diameter
1/2 inCutting Length
1/4 inShank Diameter
2 inOverall Length
2-Flute Upcut Finishing Spiral Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid CarbideUpcutRight HandSKU 1210
Choose a holder or collet for the 1/4 in shank and check the available tool clearance.
Main Product Description
This Vortex 2-flute upcut finishing spiral router bit is designed to finish routed edges and contours. It is suitable for wood and plastics.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/8 in cutting diameter and 1/2 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Technical Specifications
1210 · 2-Flute Upcut Finishing Spiral Router Bit
- Vortex
- 1210
- 2-Flute Upcut Finishing Spiral Router Bit
- 1200
- Solid Carbide
- 1/8 in
- 1/2 in
- 1/4 in
- 2 in
- 2
- Upcut
- Right Hand
Tool Configuration
general routing
edge finishing
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 1/8 in cutting diameter and 1/2 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm holder compatibility, tool projection and suitable cutting conditions for the machine and workpiece before use.
2-Flute Upcut Finishing Spiral Router Bit
Vortex 1210 is designed to finish routed edges and contours. It is suitable for wood and plastics.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/8 in cutting diameter and 1/2 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
