High-Feed Roughing Geometry
The Series 1100 design is built for rapid CNC stock removal where a separate finishing operation will establish the final edge.
Vortex Tool 1/2" × 2-1/8" 2-Flute Downcut Roughing Spiral Router Bit
CA$233.80
In stock
SKU
1165
Product Type
Two-Flute Downcut Roughing Spiral Router Bit
Series
Vortex Tool Series 1100
Cutting Geometry
Two-flute downcut roughing geometry · Right-hand cut / left-hand spiral
Cutting Diameter
1/2 in
Cutting Edge Length
2-1/8 in
Shank / Overall Length
1/2 in shank · 4 in overall length
Cutting Material
Solid Carbide
Application
High-feed CNC roughing in dense hardwoods and plywoods with downward cutting pressure and a following finishing pass
Two-Flute Downcut
Roughing Spiral
Series 1100
A Vortex Tool Series 1100 two-flute solid-carbide downcut roughing spiral with a 1/2-inch cutting diameter, 2-1/8-inch cutting-edge length, 1/2-inch shank, and 4-inch overall length. It is designed for high-feed CNC roughing where rapid stock removal and improved top-edge support are required before a separate finishing pass.
1/2 inCutting Diameter
2-1/8 inCutting Edge Length
1/2 inShank Diameter
2Flutes
2-Flute Downcut Rougher
This Series 1100 solid-carbide roughing tool uses two downcut flutes to support aggressive stock removal while directing cutting forces and chip flow downward in compatible CNC routing applications.
Solid CarbideDowncut2 FlutesSKU 1165
Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/2-inch collet or toolholder. Confirm spindle rotation, tool projection, RPM, feed, workholding, and material suitability before production use.
Main Product Description
The Vortex Tool 1165 is part of the Series 1100 two-flute downcut roughing spiral range. It is intended for high-feed CNC routing where efficient material removal and controlled top-edge quality are important, particularly in dense hardwoods and plywoods.
Its roughing geometry is designed to make the first stock-removal pass and intentionally produces a rippled edge. A compatible profile or finishing tool can then follow to create the required final surface. The downcut flute direction pushes cutting forces and chip flow downward, helping hold the workpiece against the table and supporting a cleaner top edge in compatible applications.
The verified 1165 configuration uses a 1/2-inch cutting-edge diameter, 2-1/8-inch cutting-edge length, 1/2-inch shank, and 4-inch overall length. Correct collet condition, spindle runout, tool projection, ramped entry, feed rate, RPM, cut depth, chip evacuation, and workholding remain essential to productive service.
Technical Specifications
Series 1100 · SKU 1165
- Vortex Tool
- Two-Flute Downcut Roughing Spiral Router Bit
- 1165
- 1100 — Two-Flute Downcut Roughing Spirals
- 1/2 in
- 2-1/8 in
- 1/2 in
- 4 in
- 2
- Right-Hand Cut / Left-Hand Spiral
- Solid Carbide
- Cutting Direction: Downcut · Primary Cut Behaviour: High-Feed Roughing with a Rippled Edge for a Following Finish Pass
- Dense Hardwood Roughing · Plywood Downcut Roughing · High-Feed CNC Downcut Routing
- Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/2-inch collet or toolholder. Confirm spindle rotation, tool projection, RPM, feed, workholding, and material suitability before production use.
Best Fit Applications
Dense Hardwood Roughing
Plywood Downcut Roughing
High-Feed CNC Downcut Routing
Top-Edge-Sensitive Roughing
Heavy Roughing Cuts
Product Highlights
Downward Cutting Pressure
Downcut flute direction directs cutting forces and chip flow downward, helping support part hold-down and a cleaner top edge in compatible roughing passes.
Extended Cutting Length
The 2-1/8-inch cutting length is paired with a 1/2-inch cutting diameter, 1/2-inch shank, and 4-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/2-inch collet or compatible holder, correct right-hand cutting rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cut depth, chip evacuation, workholding, and material support before use. Downcut tools should be ramped into the work rather than plunged straight into wood. This is a roughing tool and is expected to leave a rippled edge; use a compatible finishing or profile tool when the operation requires a finished surface.
High-Feed CNC Roughing
Vortex Tool 1165 combines two-flute downcut roughing geometry with a verified 1/2-inch cutting diameter, 2-1/8-inch cutting length, 1/2-inch shank, and 4-inch overall length for compatible high-feed CNC stock-removal operations.
Correct collet fit, spindle condition, tool projection, ramped entry, feed, RPM, cut depth, chip evacuation, workholding, and a planned finishing pass are essential to achieving productive roughing performance and the intended final result.
