High-Feed Roughing Geometry
The Series 1000 cutting geometry is designed for aggressive first-pass stock removal where final surface finish is not the immediate objective.
Vortex Tool 1/2" × 1-1/4" 2-Flute Upcut Roughing Spiral Router Bit
CA$170.25
In stock
SKU
1050
Product Type
Two-Flute Upcut Roughing Spiral Router Bit
Series
Vortex Tool Series 1000
Cutting Geometry
Two-flute upcut roughing geometry · Right-hand rotation
Cutting Diameter
1/2 in
Cutting Edge Length
1-1/4 in
Shank / Overall Length
1/2 in shank · 3-1/2 in overall length
Cutting Material
Solid Carbide
Application
High-feed CNC roughing in hardwoods and plywoods where a following finishing pass produces the final edge
Two-Flute Upcut
Roughing Spiral
Series 1000
A Vortex Tool Series 1000 two-flute solid-carbide upcut roughing spiral with a 1/2-inch cutting diameter, 1-1/4-inch cutting-edge length, 1/2-inch shank, and 3-1/2-inch overall length. It is designed for high-feed CNC roughing where rapid stock removal is followed by a separate finishing pass.
1/2 inCutting Diameter
1-1/4 inCutting Edge Length
1/2 inShank Diameter
2Flutes
2-Flute Upcut Rougher
This Series 1000 solid-carbide roughing tool combines two-flute upcut geometry with a serrated roughing edge for high-feed first-pass machining in compatible hardwoods, plywoods, and other dense wood materials.
Solid CarbideUpcutRoughingSKU 1050
Designed for compatible CNC routers and routing machines using a correctly sized 1/2-inch collet or toolholder. Confirm right-hand rotation, tool projection, spindle condition, RPM, feed, workholding, and chip evacuation before production use.
Main Product Description
The Vortex Tool 1050 is part of the Series 1000 two-flute upcut roughing spiral range. Vortex developed this series for high-feed CNC routing where fast material removal is more important than producing the final finished edge during the first pass.
Its upcut flute direction carries chips upward and away from the cutting zone, while the roughing geometry produces the characteristic rippled edge associated with aggressive stock removal. Vortex positions this tool for dense materials such as hardwoods and plywoods and for workflows where a profile or finishing tool follows the roughing pass.
The verified 1050 configuration uses a 1/2-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 1/2-inch shank, and 3-1/2-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cut depth, chip evacuation, and workholding remain essential to productive cutting and tool life.
Technical Specifications
Series 1000 · SKU 1050
- Vortex Tool
- Two-Flute Upcut Roughing Spiral Router Bit
- 1050
- 1000 — Two-Flute Roughing Spirals
- 1/2 in
- 1-1/4 in
- 1/2 in
- 3-1/2 in
- 2
- Right-Hand
- Solid Carbide
- Cutting Direction: Upcut · Primary Cut Behaviour: High-Feed Roughing with a Rippled Edge for a Following Finish Pass
- High-Feed CNC Roughing · Hardwood Stock Removal · Plywood Roughing
- Designed for compatible CNC routers and routing machines using a correctly sized 1/2-inch collet or toolholder. Confirm right-hand rotation, tool projection, spindle condition, RPM, feed, workholding, and chip evacuation before production use.
Best Fit Applications
High-Feed CNC Roughing
Hardwood Stock Removal
Plywood Roughing
First-Pass Profile Removal
Heavy-Cut Material Removal
Product Highlights
Upcut Chip Evacuation
Upcut flute direction carries chips upward from the cut, supporting chip removal during compatible CNC roughing operations.
Finish-Pass Workflow
The roughing pass intentionally leaves a rippled edge that can be followed with a profile or finishing tool for the final surface.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/2-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cut depth, chip evacuation, workholding, and material support before use. This is a roughing tool and is expected to leave a rippled edge; use a compatible finishing or profile tool when the operation requires a finished surface.
High-Feed CNC Roughing
Vortex Tool 1050 combines two-flute upcut roughing geometry with a verified 1/2-inch cutting diameter, 1-1/4-inch cutting length, 1/2-inch shank, and 3-1/2-inch overall length for compatible high-feed CNC stock-removal operations.
Correct collet fit, spindle condition, tool projection, feed, RPM, cut depth, chip evacuation, workholding, and a planned finishing pass are essential to achieving productive roughing performance and the intended final result.
