Triple-Flute Finish Control
The three-flute configuration supports finish-oriented routing in compatible hard plastics and solid wood applications.
Royce Ayr Triple Flute Downcut Spiral Router Bit 1/2" (12.7mm)
CA$212.60
In stock
SKU
R59-01006
Product Type
Triple-Flute Downcut CNC Router Bit
Series
Triple Flute Downcut
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/2 in (38.1 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3-1/2 in (88.9 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Hard Plastics,Finish Passes on Solid Wood
Triple-Flute Downcut Spiral
Router Bit
Triple-Flute Downcut Spiral Bit
HW solid-carbide right-hand triple-flute downcut spiral router bit designed for precision CNC routing in hard plastics and finish passes on solid wood. Its 1/2-inch cutting diameter, 1-1/2-inch cutting edge, matching 1/2-inch shank, and 3-1/2-inch overall length support controlled finishing, profiling, groove cutting, and production routing where downward cutting pressure is required.
D=1/2 in12.7 mm Diameter
CE=1-1/2 in38.1 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Triple-Flute Downcut Spiral Bit
This finish-oriented production tool combines HW solid-carbide construction, three downcut spiral flutes, right-hand rotation, no coating, and a rigid 1/2-inch shank for controlled routing in compatible hard plastics and solid wood.
HW / Solid Carbide3 FlutesRH Downcut SpiralSKU R59-01006
Designed for compatible CNC routers and routing machines using a precision 1/2-inch collet or approved toolholding assembly with right-hand rotation.
Main Product Description
The Royce Ayr Triple-Flute Downcut Spiral Router Bit R59-01006 is part of the Precision CNC Tooling and Solid Carbide Tooling lineup. It is designed for routing hard plastics and performing finish passes on solid wood where downcut geometry helps direct cutting pressure toward the workpiece surface.
The 0.5000-inch cutting diameter, 1.500-inch cutting edge, matching 0.500-inch shank, and 3.500-inch overall length provide a rigid industrial format for compatible CNC router collets and toolholders. The three-flute configuration supports finish-oriented routing where the verified cutting length, diameter, and downcut action match the operation.
This uncoated HW solid-carbide tool uses three downcut spiral flutes and right-hand rotation. RPM is not specified by the supplied source and should be confirmed before programming or production. Correct collet condition, minimum practical projection, verified runout, suitable feed rate, spindle speed, depth-per-pass, rigid workholding, machine clearance, guarding, and chip or dust extraction remain essential.
Technical Specifications
Triple-Flute Downcut Bit R59-01006
- Royce Ayr
- Triple-Flute Downcut Spiral Router Bit
- R59-01006
- Triple Flute Downcut
- Precision CNC Tooling / Solid Carbide Tooling
- 0.5000 in / 1/2 in (12.7 mm)
- 1.500 in / 1-1/2 in (38.1 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.500 in / 3-1/2 in (88.9 mm)
- 3
- Downcut Spiral
- RH / Right-Hand
- Cutting Material: HW / Solid Carbide · Coating: None · RPM: Not Specified by Supplied Source · Material Compatibility: Hard Plastics and Solid Wood Finish Passes · Primary Applications: CNC Routing, Finish Passes, Profiles, Grooves, and Downcut Surface-Control Operations · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders and RH Rotation
- Designed for compatible CNC routers and routing machines using a precision 1/2-inch collet or approved toolholding assembly with right-hand rotation.
Best Fit Applications
Hard Plastic CNC Routing
Solid Wood Finish Passes
Downcut Profile Routing
Cabinet & Millwork Production
Industrial CNC Finishing
Product Highlights
Downward Cutting Pressure
The downcut spiral geometry directs cutting pressure toward the workpiece surface during compatible CNC routing operations.
Rigid 1/2-Inch Format
The matching cutting diameter and shank support compatible CNC router setups requiring a rigid solid-carbide finishing tool.
Compatibility & Installation Notes
Confirm that the spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank, support right-hand rotation, and provide adequate clearance for the 3-1/2-inch overall length and required projection. RPM is not specified by the supplied source, so verify the operating range before programming or production. Match feed speed, cutting depth, material suitability, workholding, guarding, chip or dust extraction, and machine clearance to the specific operation.
Improve Finish-Oriented Downcut Routing
The Royce Ayr Triple-Flute Downcut Spiral Router Bit R59-01006 provides an uncoated HW solid-carbide solution for routing hard plastics and performing finish passes on solid wood.
Its 1/2-inch cutting diameter, 1-1/2-inch cutting edge, matching shank, three-flute downcut geometry, right-hand rotation, and 3-1/2-inch overall length support controlled production routing when correctly held and operated.
