Royce Ayr Ultimax Double Flute Mortise Compression Router Bit 1/2 in (12.7 mm)
2-Flute Ultimax Mortise Compression
Router Bit
Ultimax-coated, two-flute mortise compression router bit for laminated or veneered wood and wood composites where top and bottom finish is critical. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, 0.230-inch upcut section, 1/2-inch shank, and 3-inch overall length suit compatible nested CNC routing systems.
Main Product Description
The Royce Ayr 2-Flute Ultimax Mortise Compression Router Bit R60-12004UM belongs to Royce Ayr's R60-120 Double Flute Mortise Compression series. It is intended for routing laminated or veneered wood and wood composites when finished top and bottom edges are important.
Its compression geometry combines upward and downward cutting action to reduce chipping on laminated faces. The short 0.230-inch (5.842 mm) upcut section supports compatible dado-routing operations when the cutting depth and entry strategy place the compression transition correctly within the workpiece.
Royce Ayr specifies Ultimax coating to minimize friction, increase edge hardness, provide strong coating adhesion, and support tool life in nested-routing applications. Before machining, verify toolholding, runout, right-hand rotation, tool projection, spindle speed, feed rate, pass depth, workholding, and chip extraction.
Best Fit Applications
Product Highlights
Ultimax Coating
Royce Ayr specifies the coating to minimize friction, increase edge hardness, provide strong adhesion, and support tool life in nested routing.
Short-Upcut Compression
The 0.230-inch upcut section supports compatible dado routing when the compression transition is positioned correctly within the panel.
Compact 1/2-Inch Format
The 1/2-inch diameter and shank, 1-1/8-inch cutting edge, and 3-inch overall length suit compatible CNC production setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, pass depth, workholding, and chip extraction. Position the 0.230-inch (5.842 mm) upcut section and compression transition correctly within the material.
Improve Finish-Sensitive Panel Routing
The Royce Ayr 2-Flute Ultimax Mortise Compression Router Bit R60-12004UM provides a coated solid-carbide solution for laminated, veneered, and wood-composite panel routing where top and bottom finish is critical.
Its 1/2-inch diameter and shank, 1-1/8-inch cutting edge, 0.230-inch upcut section, two-flute compression geometry, Ultimax coating, and 3-inch overall length suit compatible nested CNC systems when correctly held and operated.
