Mortise Compression Geometry
Opposing cutting directions support clean top and bottom edges in compatible laminated and veneered materials.
Royce Ayr 2 Flute Mortise Compression Router Bit 1/2" (12.7mm)
CA$999.99
Out of stock
SKU
R60-12004
Product Type
2 Flute Mortise Compression Router Bit
Series
Double Flute Mortise Compression / R60-120 Series
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Upcut Length
0.230 in (5.84 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated,Veneered and Wood-Composite Panel Routing
2-Flute
Mortise Compression
Router Bit
Solid-carbide mortise compression router bit for laminated or veneered wood and wood composites where top and bottom finish is critical. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, 0.230-inch upcut section, 1/2-inch shank, and 3-inch overall length suit compatible CNC routing systems.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.575 mm Cutting Edge
UC=0.230 in5.842 mm Upcut Length
OAL=3 in76.2 mm Overall Length
Mortise Compression
This two-flute solid-carbide tool combines upward and downward shearing action with a short upcut section to support clean routing on both faces of compatible laminated and veneered panels.
Solid Carbide / HW2 FlutesMortise CompressionSKU R60-12004
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system. The 0.230-inch upcut section must be positioned correctly within the material for the intended compression effect.
Main Product Description
The Royce Ayr 2-Flute Mortise Compression Router Bit R60-12004 belongs to Royce Ayr's Double Flute Mortise Compression series. It is intended for routing laminated or veneered wood and wood composites when finished top and bottom edges are important.
Its compression geometry combines upward and downward cutting action to prevent chipping on laminated faces. The short 0.230-inch (5.842 mm) upcut section supports compatible dado-routing operations when the cutting depth and entry strategy place the compression transition correctly within the workpiece.
The 0.5000-inch cutting diameter, 1.125-inch cutting edge, 0.500-inch shank, and 3.000-inch overall length require a compatible precision collet or approved toolholder. Before machining, verify collet condition, runout, right-hand rotation, tool projection, spindle speed, feed rate, pass depth, workholding, and chip extraction.
Technical Specifications
Mortise Compression R60-12004
- Royce Ayr
- 2-Flute Mortise Compression Router Bit
- R60-12004
- Double Flute Mortise Compression
- Solid Carbide CNC Routing Tooling
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.575 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- RH / Right Hand
- HW / Solid Carbide · Mortise Compression · Uncoated
- Laminated or Veneered Wood and Wood Composites
- Compatible CNC Router
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Wood-Composite Machining
Mortise Compression Routing
Chip-Conscious Dado Routing
Product Highlights
Short-Upcut Section
The 0.230-inch upcut section supports chip-conscious dado routing when the compression transition is positioned correctly.
Compact 1/2-Inch Format
The 1/2-inch diameter and shank, 1-1/8-inch cutting edge, and 3-inch overall length suit compatible CNC production setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, pass depth, workholding, and chip extraction. Position the 0.230-inch (5.842 mm) upcut section and compression transition correctly within the material.
Improve Finish-Sensitive Panel Routing
The Royce Ayr 2-Flute Mortise Compression Router Bit R60-12004 provides a solid-carbide solution for laminated, veneered, and wood-composite panel routing where top and bottom finish is critical.
Its 1/2-inch diameter and shank, 1-1/8-inch cutting edge, 0.230-inch upcut section, two-flute compression geometry, and 3-inch overall length suit compatible CNC systems when correctly held and operated.
