Ultimax Coating
Royce Ayr specifies the coating for reduced friction, increased edge hardness, strong adhesion, and extended tool life in nested routing.
Royce Ayr Ultimax Triple Flute Compression Router Bit 1/2" (12.7mm)
CA$999.99
Out of stock
SKU
R60-11502UM
Product Type
Ultimax Triple Flute Compression Router Bit
Series
Triple Flute Compression
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Upcut Length
3/8 in (9.53 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HC Source Designation
Coating
Ultimax
Application
Nested Routing of Laminated,Veneered and Wood-Composite Panels
3-Flute Ultimax Compression
Router Bit
Ultimax Triple-Flute Compression
Ultimax-coated triple-flute compression router bit for laminated or veneered wood and wood composites where top and bottom finish is critical. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, 3/8-inch upcut section, 1/2-inch shank, and 3-inch overall length suit compatible nested CNC routing systems.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.575 mm Cutting Edge
UC=3/8 in9.525 mm Upcut Length
OAL=3 in76.2 mm Overall Length
Ultimax Triple-Flute Compression
This three-flute solid-carbide tool combines upward and downward shearing action to support clean routing on both faces of compatible laminated, veneered, and wood-composite panels.
Solid Carbide / HC3 FlutesUltimax CoatedSKU R60-11502UM
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system. The 3/8-inch upcut section must be positioned correctly within the material for the intended compression effect.
Main Product Description
The Royce Ayr 3-Flute Ultimax Compression Router Bit R60-11502UM belongs to Royce Ayr's Triple Flute Compression series. It is intended for routing laminated or veneered wood and wood composites when finished top and bottom edges are important.
Its compression geometry combines upward and downward cutting action to prevent chipping on laminated faces. The 0.375-inch (9.525 mm) upcut section supports chip-free dado routing when the cutting depth and entry strategy position the compression transition correctly within the workpiece.
Royce Ayr specifies Ultimax coating for reduced friction, increased edge hardness, strong coating adhesion, and extended tool life in nested-routing applications. Before machining, verify toolholding, runout, right-hand rotation, tool projection, spindle speed, feed rate, pass depth, workholding, and chip extraction.
Technical Specifications
Ultimax Compression R60-11502UM
- Royce Ayr
- 3-Flute Ultimax Compression Router Bit
- R60-11502UM
- Triple Flute Compression
- HC
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.575 mm)
- 0.375 in / 3/8 in (9.525 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 3
- Triple-Flute Compression
- Rotation: RH / Right Hand · Coating: Ultimax · Material Compatibility: Laminated or Veneered Wood and Wood Composites · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system. The 3/8-inch upcut section must be positioned correctly within the material for the intended compression effect.
Best Fit Applications
Nested CNC Routing
Laminated Panel Routing
Veneered Panel Routing
Wood-Composite Machining
Chip-Free Dado Routing
Product Highlights
Triple-Flute Compression
The three-flute compression geometry provides a production-focused option where controlled top and bottom edge finish is required.
Short Upcut Section
The 3/8-inch upcut section supports chip-free dado routing when the compression transition is positioned correctly.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, pass depth, workholding, and chip extraction. Position the 0.375-inch (9.525 mm) upcut section and compression transition correctly within the material.
Improve Finish-Critical Panel Routing
The Royce Ayr 3-Flute Ultimax Compression Router Bit R60-11502UM provides an Ultimax-coated solid-carbide solution for laminated, veneered, and wood-composite panel routing where top and bottom finish is critical.
Its 1/2-inch diameter and shank, 1-1/8-inch cutting edge, 3/8-inch upcut section, triple-flute compression geometry, Ultimax coating, and 3-inch overall length suit compatible CNC systems when correctly held and operated.
