Royce Ayr Triple Flute Compression Router Bit 1/2 in (12.7 mm)
2-Flute Compression Spiral
Router Bit
Large-format solid-carbide compression spiral router bit for laminated or veneered wood and wood composites where top and bottom finish is critical. Its 3/4-inch cutting diameter, 2-1/2-inch cutting edge, 1-1/4-inch upcut section, 3/4-inch shank, and 5-inch overall length suit compatible CNC panel-routing systems.
Main Product Description
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11408 belongs to Royce Ayr's Double Flute Compression series. It is intended for routing laminated or veneered wood and wood composites when finished top and bottom edges are important.
Its compression geometry combines upward and downward cutting action to prevent chipping on laminated faces. The 1.250-inch (31.75 mm) upcut section must be matched to the material thickness and programmed cut depth so the compression transition remains correctly positioned within the workpiece.
The 0.7500-inch cutting diameter, 2.500-inch cutting edge, 0.750-inch shank, and 5.000-inch overall length require rigid, low-runout toolholding and adequate machine clearance. Before machining, verify collet condition, right-hand rotation, tool projection, spindle speed, feed rate, pass depth, workholding, and chip extraction.
Best Fit Applications
Product Highlights
Large 3/4-Inch Format
The 3/4-inch cutting diameter and shank suit compatible heavy-duty CNC panel-routing systems and approved toolholders.
Extended Cutting Reach
The 2-1/2-inch cutting edge and 5-inch overall length provide extended reach for compatible panel-processing applications.
Compression Transition
The 1-1/4-inch upcut section must be matched carefully to material thickness and programmed cutting depth.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 3/4-inch (19.05 mm) shank and provides sufficient clearance for the 5-inch (127 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, pass depth, workholding, and chip extraction. Position the 1.250-inch (31.75 mm) upcut section and compression transition correctly within the material.
Extend Large-Format Compression Routing
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11408 provides a solid-carbide solution for laminated, veneered, and wood-composite panel routing where top and bottom finish is critical.
Its 3/4-inch diameter and shank, 2-1/2-inch cutting edge, 1-1/4-inch upcut section, two-flute compression geometry, and 5-inch overall length suit compatible CNC systems when correctly held and operated.
