Ultimax Coating
This coated version is distinct from the uncoated tool with otherwise matching primary dimensions and production geometry.
Royce Ayr Ultimax Double Flute Compression Spiral Bit 1/2" (12.7mm)
CA$214.90
In stock
SKU
R60-11413UM
Product Type
Double Flute Compression Spiral CNC Router Bit
Series
Double Flute Compression
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-3/4 in (44.45 mm)
Upcut Length
3/4 in (19.05 mm)
Shank
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flutes
2
Rotation
Right-Hand (RH)
Coating
Ultimax
Application
Laminated,Veneered and Wood-Composite Panel Routing
2-Flute Ultimax Compression
Spiral Router Bit
Ultimax Compression Bit
An Ultimax-coated solid-carbide compression spiral router bit for CNC routing laminated, veneered, and wood-composite panels where clean top and bottom edges are required. Its 1/2-inch cutting diameter and shank, 1-3/4-inch cutting edge, 3/4-inch upcut section, and 4-inch overall length provide a balanced production-routing format.
D=1/2 in12.7 mm Diameter
CE=1-3/4 in44.45 mm Cutting Edge
Up=3/4 in19.05 mm Upcut
OAL=4 in101.6 mm Overall Length
Ultimax Compression Bit
This production tool combines solid-carbide construction, two compression flutes, right-hand rotation, and Royce Ayr's Ultimax coating for compatible nested-routing and panel-processing applications.
Solid CarbideUltimax Coated2 Flutes · RHSKU R60-11413UM
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 3/4-inch upcut section and 1-3/4-inch cutting edge to the panel thickness, programmed depth, and required compression transition.
Main Product Description
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11413UM is built for CNC routing applications in industrial woodworking, cabinet-component production, millwork, and panel-processing environments. Its compression geometry combines upward and downward shearing action to help reduce chipping on laminated or veneered materials where both faces require a clean finish.
The tool features a 0.5000-inch cutting diameter, 1.750-inch cutting edge, 0.750-inch upcut section, 0.500-inch shank, two flutes, right-hand rotation, Ultimax coating, and a 4.000-inch overall length. This configuration offers a balanced combination of cutting reach, rigidity, and edge control for compatible cabinet, millwork, window-and-door, stair, railing, and panel-processing applications.
The Ultimax coating distinguishes this model from the uncoated tool with otherwise matching primary dimensions. The 3/4-inch upcut section must be positioned correctly for the material thickness and programmed depth so the compression transition engages the workpiece as intended. Correct collet condition, tool projection, spindle speed, feed rate, pass strategy, hold-down, chip evacuation, and dust extraction remain essential.
Technical Specifications
Ultimax Compression R60-11413UM
- Royce Ayr
- 2-Flute Ultimax Compression Spiral Router Bit
- R60-11413UM
- Double-Flute Compression
- 0.5000 in / 1/2 in (12.7 mm)
- 1.750 in / 1-3/4 in (44.45 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 2
- RH / Right Hand
- Ultimax
- Material: Solid Carbide Tooling · Material Compatibility: Laminated Wood, Veneered Wood, and Wood Composites · Industry Fit: Window & Door, Moulding & Millwork, Stairs & Railings · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders · Application: Routing Where Top and Bottom Finish Is Critical
- Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 3/4-inch upcut section and 1-3/4-inch cutting edge to the panel thickness, programmed depth, and required compression transition.
Best Fit Applications
Laminated Panel Routing
Veneered Wood Routing
Wood-Composite Machining
Nested CNC Processing
Millwork, Stair & Door Production
Product Highlights
Compression Edge Control
Upward and downward shearing action helps reduce chipping on both faces of compatible laminated and veneered panels.
Balanced Production Geometry
The 1-3/4-inch cutting edge and 3/4-inch upcut section suit compatible CNC panel-routing applications.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank. Verify right-hand rotation, tool projection, runout, available clearance, guarding, dust extraction, hold-down, RPM, feed rate, ramping strategy, number of passes, and material thickness before machining. Position the 3/4-inch upcut section and remaining downcut geometry correctly for the intended routing operation.
Coated Two-Sided Panel Routing
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11413UM provides a coated solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 1/2-inch diameter and shank, 1-3/4-inch cutting edge, 3/4-inch upcut section, and 4-inch overall length support balanced production-routing applications.
Two-flute compression geometry, right-hand rotation, and the Ultimax coating support controlled panel machining when the tool is correctly held, positioned through the material, and operated within suitable machining parameters.
