Long Cutting Edge
The 2-1/2-inch cutting edge supports compatible deeper cutting applications where machine clearance and collet grip are confirmed.
Royce Ayr 2 Flute Compression Spiral Router Bit 1/2" (12.7mm) – 2-Flute
CA$264.15
In stock
SKU
R60-11410
Product Type
2-Flute Compression Spiral Router Bit
Series
R60-114 2-Flute Compression
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
2-1/2 in (63.5 mm)
Upcut Section
1-1/8 in (28.58 mm)
Shank
1/2 in (12.7 mm)
Overall Length
5 in (127 mm)
Flutes
2
Material
HW
Coating
None
Application
Laminated,Veneered and Wood Composite Panel Routing
2-Flute
Compression
Spiral Router Bit
A solid-carbide compression spiral router bit with a 1/2-inch cutting diameter, 2-1/2-inch cutting edge, 1-1/8-inch upcut section, 1/2-inch shank, and 5-inch overall length for compatible CNC routing of laminated, veneered, and wood-composite panels.
D=1/2 in12.7 mm Diameter
CE=2-1/2 in63.5 mm Cutting Edge
Up=1-1/8 in28.58 mm Upcut
OAL=5 in127 mm Overall Length
Compression Router Bit
This production tool combines solid-carbide construction, two compression flutes, and right-hand rotation to help control chipping on both faces of compatible laminated, veneered, and composite panels.
Solid Carbide2 FlutesRight-HandSKU R60-11410
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Confirm spindle capacity, machine clearance, usable flute length, tool projection, and panel thickness before using the extended cutting geometry.
Main Product Description
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11410 is designed for CNC routing and industrial panel-processing applications where both the top and bottom faces of the material require a clean finished edge. Its compression geometry combines upward and downward shearing action to help reduce chipping on laminated and veneered surfaces.
The tool features a 0.5000-inch cutting diameter, 2.500-inch cutting edge, 1.125-inch upcut section, 0.500-inch shank, two flutes, right-hand rotation, no coating, and a 5.000-inch overall length. The extended cutting edge supports compatible deeper cutting requirements where machine clearance, collet grip, and material thickness are properly confirmed.
Cutting depth must position the upcut and downcut sections correctly through the material to achieve the intended compression action. Correct collet condition, tool projection, spindle speed, feed rate, pass strategy, panel hold-down, chip evacuation, and dust extraction remain essential for maintaining finish quality and tool life.
Technical Specifications
Compression Router Bit R60-11410
- Royce Ayr
- 2-Flute Compression Spiral Router Bit
- R60-11410
- R60-114 2-Flute Compression
- Solid Carbide / Precision CNC Tooling
- 0.5000 in / 1/2 in (12.7 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 5.000 in / 5 in (127 mm)
- 2
- RH / Right Hand
- HW / Solid Carbide Tooling · Uncoated
- Laminated Wood, Veneered Wood, and Wood Composites
- CNC Routers with Compatible 1/2-Inch Collets or Toolholders
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Wood-Composite Machining
Deep Through-Cutting
Cabinet & Millwork Processing
Product Highlights
Common 1/2-Inch Format
The 1/2-inch cutting diameter and shank suit compatible industrial CNC router toolholding systems.
Compression Transition
The 1-1/8-inch upcut section must be positioned correctly within the panel thickness to achieve the intended edge quality.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and can safely accommodate the 5-inch overall length and 2-1/2-inch cutting edge. Verify right-hand rotation, tool projection, runout, usable flute length, available clearance, guarding, dust extraction, hold-down, RPM, feed rate, pass strategy, and material thickness before machining. Position the 1-1/8-inch upcut section and remaining downcut geometry correctly through the workpiece.
Deep Two-Sided Panel Routing
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11410 provides a solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 1/2-inch diameter and shank, 2-1/2-inch cutting edge, 1-1/8-inch upcut section, and 5-inch overall length support compatible deeper production-routing applications.
Two-flute compression geometry and right-hand rotation support controlled panel machining when the tool is correctly held, positioned through the material, and operated within suitable machining parameters.
