Royce Ayr 2 Flute Compression Router Bit 5/8 in (15.88 mm)
2-Flute Compression
Spiral Router Bit
A large-format solid-carbide compression spiral router bit for CNC routing laminated, veneered, and wood composite panels where clean top and bottom edges are required. Its 5/8-inch cutting diameter and shank, 2-1/4-inch cutting edge, 1-1/8-inch upcut section, and 5-inch overall length suit compatible heavier production-routing applications.
Main Product Description
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11406 is built for CNC routing laminated panels, veneered wood, and compatible wood composite materials where edge quality is important on both faces of the workpiece. Its compression geometry combines upward and downward shearing action to help reduce chipping at the top and bottom surfaces.
The tool features a 5/8-inch (15.88 mm) cutting diameter, 2-1/4-inch (57.15 mm) cutting edge, 1-1/8-inch (28.58 mm) upcut section, 5/8-inch (15.88 mm) shank, two flutes, and a 5-inch (127 mm) overall length. This larger configuration suits compatible heavier panel-routing work where the machine, spindle, toolholder, and material thickness support the tool format.
The 1-1/8-inch upcut section must be considered when establishing cutting depth, entry strategy, spoilboard allowance, and panel position so the compression transition engages the workpiece correctly. Rotation and coating are not specified in the supplied source and should be confirmed before production use.
Best Fit Applications
Product Highlights
Large-Format Compression
The 5/8-inch cutting diameter and shank suit compatible heavier-duty panel-routing applications with suitable machine power and toolholding.
Extended Cutting Edge
The 2-1/4-inch cutting edge supports compatible deeper panel-routing work where clearance, spindle capacity, and material thickness are confirmed.
Long Upcut Section
The 1-1/8-inch upcut section must be positioned correctly within the material to achieve the intended compression action.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder are rated for a 5/8-inch (15.88 mm) shank compression router bit. Verify the required rotation direction, safe RPM, feed speed, cutting depth, tool projection, available clearance, material thickness, guarding, dust extraction, spoilboard condition, machine power, and toolholder runout before production use. Position the 1-1/8-inch upcut section and remaining compression geometry correctly through the workpiece.
Large-Format Two-Sided Routing
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11406 provides a solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 5/8-inch diameter and shank, 2-1/4-inch cutting edge, 1-1/8-inch upcut section, and 5-inch overall length support compatible large-format production-routing applications.
The larger tool format requires correctly rated toolholding, adequate spindle power, suitable clearance, secure workholding, and machining parameters matched to the actual panel material and cutting depth.
