Compression Edge Control
Upward and downward shearing action helps reduce chipping on the top and bottom faces of compatible laminated and veneered panels.
Royce Ayr 2 Flute Ultimax Compression Spiral Router Bit 1/2" (12.7mm) – Right-Hand – 2-Flute – 1-1/8"
CA$176.55
In stock
SKU
R60-11403UM
Product Type
2 Flute Ultimax Compression Spiral Router Bit
Series
R60-114 Compression 2 Flutes
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Upcut Length
0.400 in (10.16 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HC
Coating
Ultimax
Application
Laminated,Veneered and Wood Composite Nested Routing
2-Flute Ultimax
Compression
Spiral Router Bit
An Ultimax-coated solid-carbide compression spiral router bit for CNC routing laminated or veneered wood and wood composites where clean top and bottom edge finish is critical. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, 0.400-inch upcut section, 1/2-inch shank, and 3-inch overall length suit compact production panel-routing applications.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
Up=0.400 in10.16 mm Upcut
OAL=3 in76.2 mm Overall Length
Ultimax Compression Bit
This coated production tool combines solid-carbide construction, two compression flutes, and right-hand rotation to help control chipping on both faces of compatible laminated, veneered, and composite panels.
Solid CarbideUltimax Coated2 Flutes · RHSKU R60-11403UM
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 0.400-inch upcut section and 1-1/8-inch cutting edge to the panel thickness and programmed cutting depth.
Main Product Description
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11403UM is engineered for CNC routing laminated or veneered wood and wood composite panels where both the top and bottom surfaces require controlled edge quality. Its compression geometry combines upward and downward shearing action to help reduce chipping on both faces of the material.
The tool features a 0.5000-inch cutting diameter, 1.125-inch cutting edge, 0.400-inch upcut section, 0.500-inch shank, two flutes, right-hand rotation, Ultimax coating, and a 3.000-inch overall length. This compact configuration is suited to compatible cabinet, millwork, nested-routing, and general panel-processing applications.
Royce Ayr identifies the Ultimax coating as a low-friction, high-hardness coating with strong adhesion intended to support extended tool life in nested-routing applications. Correct collet condition, tool projection, spindle speed, feed rate, material thickness, hold-down, and depth-per-pass remain essential for maintaining finish quality and tool life.
Technical Specifications
Ultimax Compression Bit R60-11403UM
- Royce Ayr
- 2-Flute Ultimax Compression Spiral Router Bit
- R60-11403UM
- R60-114 Compression 2 Flutes / Ultimax
- Solid Carbide / Precision CNC Tooling
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.58 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- RH / Right Hand
- HC / Solid Carbide Tooling · Ultimax Coating
- Laminated Wood, Veneered Wood, and Wood Composites
- CNC Routers with Compatible 1/2-Inch Collets or Toolholders
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Wood Composite Machining
Nested CNC Routing
Cabinet & Millwork Production
Product Highlights
Ultimax Coating
The coating is specified to minimize friction, increase edge hardness, provide strong adhesion, and support extended life in nested-routing applications.
Verified Cutting Geometry
The 1-1/8-inch cutting edge and 0.400-inch upcut section can be matched carefully to panel thickness and programmed cutting depth.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank. Verify right-hand rotation, tool projection, runout, available clearance, guarding, dust extraction, hold-down, RPM, feed rate, pass depth, and material thickness before machining. Compression tools must be positioned so the 0.400-inch upcut section and remaining downcut geometry engage the workpiece correctly; confirm that the 1-1/8-inch cutting edge suits the panel and programmed cutting depth.
Coated Two-Sided Panel Routing
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11403UM provides a coated solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 1/2-inch diameter, 1-1/8-inch cutting edge, 0.400-inch upcut section, 1/2-inch shank, and 3-inch overall length support compact production-routing applications.
Two-flute compression geometry, right-hand rotation, and the Ultimax coating support controlled panel machining when the tool is correctly held, positioned through the material, and operated within suitable machining parameters.
