Compression Edge Control
Upward and downward shearing action helps reduce chipping on the top and bottom faces of compatible laminated and veneered panels.
Royce Ayr Double Flute Compression Router Bit 1/2" (12.7mm) – Right-Hand – 2-Flute – 1-1/8"
CA$149.75
In stock
SKU
R60-11403
Product Type
Double Flute Compression Router Bit
Series
Double Flute Compression / R60-114 Series
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Upcut Length
0.400 in (10.16 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated,Veneered and Wood Composite Routing
Double Flute Compression
Router Bit
Compression Router Bit
Solid-carbide, right-hand compression router bit designed for CNC routing laminated or veneered wood and wood composites where clean top and bottom edge finish is critical. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, 0.400-inch upcut section, 1/2-inch shank, and 3-inch overall length suit compact production panel-routing applications.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
Up=0.400 in10.16 mm Upcut
OAL=3 in76.2 mm Overall Length
Compression Router Bit
This production-grade tool combines a rigid solid-carbide body, two compression flutes, and right-hand rotation to help control chipping on both faces of compatible laminated, veneered, and composite panels.
Solid Carbide2 FlutesRight-HandSKU R60-11403
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 0.400-inch upcut section and 1-1/8-inch cutting edge to the panel thickness and programmed cutting depth.
Main Product Description
The Royce Ayr Double Flute Compression Router Bit R60-11403 is engineered for CNC routing laminated or veneered wood and wood composite panels where both the top and bottom surfaces require controlled edge quality. Its compression geometry combines upward and downward shearing action to help reduce chipping on both faces of the material.
The tool features a 0.5000-inch cutting diameter, 1.125-inch cutting edge, 0.400-inch upcut section, 0.500-inch shank, two flutes, right-hand rotation, and a 3.000-inch overall length. This compact configuration is suited to compatible cabinet, millwork, window-and-door, stair-and-railing, and general panel-processing applications.
Solid-carbide construction supports cutting-edge retention, rigidity, and dimensional consistency in production routing. Correct collet condition, tool projection, spindle speed, feed rate, material thickness, hold-down, and depth-per-pass are essential for maintaining finish quality and tool life.
Technical Specifications
Compression Router Bit R60-11403
- Royce Ayr
- Double Flute Compression Router Bit
- R60-11403
- Double Flute Compression / R60-114 Series
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.58 mm)
- 0.400 in (10.16 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- RH / Right Hand
- None
- Construction: HW / Solid Carbide · Material Compatibility: Laminated Wood, Veneered Wood, and Wood Composites · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders · Industries: Window and Door, Moulding and Millwork, Stairs and Railings · Country of Origin: Not Specified by Source
- Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 0.400-inch upcut section and 1-1/8-inch cutting edge to the panel thickness and programmed cutting depth.
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Wood Composite Machining
Cabinet & Millwork Production
Window, Door & Stair Components
Product Highlights
Compact 1/2-Inch Format
The 1/2-inch cutting diameter and shank with a 1-1/8-inch cutting edge suit compatible production panel-routing applications.
Verified Upcut Section
The 0.400-inch upcut length can be matched carefully to panel thickness and programmed cutting depth for correct compression engagement.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank. Verify right-hand rotation, tool projection, runout, available clearance, guarding, dust extraction, hold-down, RPM, feed rate, pass depth, and material thickness before machining. Compression tools must be positioned so the 0.400-inch upcut section and remaining downcut geometry engage the workpiece correctly; confirm that the 1-1/8-inch cutting edge suits the panel and programmed cutting depth.
Improve Two-Sided Panel Finish
The Royce Ayr Double Flute Compression Router Bit R60-11403 provides a solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 1/2-inch diameter, 1-1/8-inch cutting edge, 0.400-inch upcut section, 1/2-inch shank, and 3-inch overall length support compact production-routing applications.
Two-flute compression geometry and right-hand rotation help control face chipping and maintain consistent routed dimensions when the tool is correctly held, positioned through the material, and operated within suitable machining parameters.
