Serrated Tooth Efficiency
The serrated cutting design is engineered to minimize the horsepower required during compatible door-mortising operations.
Royce Ayr 3 Flute Upcut Lock Mortise Tool 3/4" (19.05mm)
CA$999.99
Out of stock
SKU
R60-01758UM
Product Type
3 Flute Upcut Lock Mortise Tool
Series
Lock Mortise Tool Upcut
Cutting Diameter
3/4 in (19.05 mm)
Cutting Edge
2 in (50.8 mm)
Dimension b1
1-1/2 in (38.1 mm)
Dimension b2
5-1/2 in (139.7 mm)
Shank
3/4 in (19.05 mm)
Overall Length
7 in (177.8 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HC
Coating
Ultimax
Application
Deep CNC Door Lock-Set Mortising
3-Flute Upcut
Lock Mortise Tool
Upcut Lock Mortise Tool
Ultimax-coated solid-carbide, right-hand upcut lock-mortise tool designed for CNC machining lock-set pockets in the sides of doors. Its 3/4-inch cutting diameter, 2-inch cutting edge, 3/4-inch shank, and 7-inch overall length support compatible deep-mortising operations.
D=3/4 in19.05 mm Diameter
CE=2 in50.8 mm Cutting Edge
Sh=3/4 in19.05 mm Shank
OAL=7 in177.8 mm Overall Length
Upcut Lock Mortise Tool
Purpose-built for door lock-set mortising, this solid-carbide tool combines three upcut flutes, serrated tooth geometry, spinback relief, and Royce Ayr Ultimax coating for compatible deep-mortise CNC routing.
Solid Carbide3 FlutesRight-HandSKU R60-01758UM
Designed for compatible CNC routers using precision 3/4-inch collets or approved toolholding systems with sufficient projection, clearance, and machine travel for door-side mortising.
Main Product Description
The Royce Ayr 3-Flute Upcut Lock Mortise Tool R60-01758UM is designed for CNC routing of lock-set mortises in the sides of doors. Its dedicated geometry gives door and architectural-millwork producers a production tool for machining deep lock pockets where the verified 3/4-inch diameter, 2-inch cutting edge, and 7-inch overall length match the programmed operation.
Royce Ayr uses a serrated tooth design to reduce the horsepower required during cutting, while the spinback feature provides relief during deep-mortise machining. The three-flute upcut configuration supports chip evacuation from the cut and is intended for right-hand spindle rotation in compatible CNC router systems.
The tool has a 1-1/2-inch b1 dimension, 5-1/2-inch b2 dimension, 3/4-inch shank, solid-carbide/HW construction, and Ultimax coating. Correct collet condition, tool projection, runout, spindle speed, feed rate, plunge strategy, pass depth, workholding, and chip extraction are essential for safe, repeatable lock-mortise production.
Technical Specifications
Lock Mortise Tool R60-01758UM
- Royce Ayr
- 3-Flute Upcut Lock Mortise Tool
- R60-01758UM
- Lock Mortise Tool Upcut
- 0.7500 in / 3/4 in (19.05 mm)
- 2.000 in / 2 in (50.8 mm)
- 1.500 in / 1-1/2 in (38.1 mm)
- 5.500 in / 5-1/2 in (139.7 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 7.000 in / 7 in (177.8 mm)
- 3
- RH / Right Hand
- Coating: Ultimax · Active Cutting Material: HW / Solid Carbide · Cutting Geometry: Upcut with Serrated Tooth Design and Spinback Relief · Machine Type: CNC Router · Primary Application: Mortising Door Sides for Lock-Set Installation · Industries: Window & Door, Moulding & Millwork, and Stairs & Railings
- Designed for compatible CNC routers using precision 3/4-inch collets or approved toolholding systems with sufficient projection, clearance, and machine travel for door-side mortising.
Best Fit Applications
Door Lock-Set Mortising
Deep Mortise Routing
Door Production
Architectural Millwork
CNC Router Operations
Product Highlights
Spinback Deep-Mortise Relief
Spinback geometry provides relief while the tool machines deeper lock pockets, supporting controlled clearance in the cut.
Ultimax-Coated Solid Carbide
Solid-carbide/HW construction and Royce Ayr Ultimax coating support production use where the tool geometry and cutting parameters are correctly matched.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, chuck, or toolholder accepts an exact 3/4-inch (19.05 mm) shank and safely supports the required tool projection. Verify right-hand rotation, collet condition, runout, spindle speed, feed rate, plunge strategy, pass depth, cutting depth, door material, fixturing, part hold-down, machine clearance, guarding, and dust extraction before machining. Confirm that the 7-inch overall length, 2-inch cutting edge, 1-1/2-inch b1 dimension, and 5-1/2-inch b2 dimension match the programmed lock-mortise operation.
Machine Deep Lock Mortises with Dedicated Geometry
The Royce Ayr 3-Flute Upcut Lock Mortise Tool R60-01758UM provides a purpose-built solid-carbide solution for CNC door and architectural-millwork production. Its 3/4-inch cutting diameter, 2-inch cutting edge, 3/4-inch shank, and 7-inch overall length are configured for compatible lock-set mortising applications.
Serrated teeth help reduce cutting-power demand, spinback geometry provides relief in deep mortises, and the Ultimax-coated right-hand configuration supports repeatable production when toolholding, programming, feeds, speeds, workholding, and chip evacuation are correctly established.
