Dedicated Lock Mortise Geometry
Designed for CNC routing deep mortises in the sides of doors where accurate and repeatable lock-set pocket machining is required.
Royce Ayr Lock Mortise Tool Upcut 1/2" (12.7mm)
CA$509.60
Out of stock
SKU
R60-01742
Product Type
3 Flute Lock Mortise Upcut Tool
Series
Lock Mortise Tool Upcut
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/2 in (38.1 mm)
Dimension b1
1-1/2 in (38.1 mm)
Dimension b2
4-1/2 in (114.3 mm)
Shank
1/2 in (12.7 mm)
Overall Length
6 in (152.4 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Deep CNC Door Lock-Set Mortising
3-Flute Lock Mortise
Upcut Tool
Deep Lock Mortise Upcut Tool
Uncoated HW solid-carbide right-hand 3-flute lock-mortise upcut tool designed for CNC routing of deep mortises in the sides of doors for lock-set hardware. Its serrated tooth design helps reduce cutting horsepower demand, while the upcut action supports chip evacuation and the spinback relief provides clearance during deep mortise cutting. The tool features a 1/2-inch cutting diameter, 1-1/2-inch cutting edge, matching 1/2-inch shank, and 6-inch overall length.
D=1/2 in12.7 mm Diameter
CE=1-1/2 in38.1 mm Cutting Edge
b2=4-1/2 in114.3 mm Dimension
OAL=6 in152.4 mm Overall Length
Deep Lock Mortise Upcut Tool
This extended-reach door-machining tool combines HW solid-carbide construction, three upcut flutes, right-hand rotation, serrated tooth geometry, and spinback relief for repeatable deep lock-mortise production.
HW / Solid Carbide3 FlutesRH UpcutSKU R60-01742
Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly, right-hand spindle rotation, and sufficient reach and clearance for the 6-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Lock Mortise Upcut Tool R60-01742 is built for door-production and millwork shops that need to machine deep side mortises for lock-set hardware. It is part of Royce Ayr's solid-carbide CNC router tooling range and uses a serrated tooth design intended to reduce horsepower demand during cutting.
The upcut action supports chip evacuation, while the spinback relief provides clearance through deep mortise cuts. Its 1/2-inch cutting diameter, 1-1/2-inch cutting edge, 1-1/2-inch b1 dimension, 4-1/2-inch b2 dimension, matching 1/2-inch shank, and 6-inch overall length suit production environments where door-hardware pockets must be routed accurately and repeatedly.
This model is the uncoated HW solid-carbide right-hand configuration with three flutes. It is suited to window-and-door manufacturing, moulding and millwork, stairs and railings, and related applications requiring extended-reach lock-mortise machining. RPM/feed data and country of origin are not specified by the supplied source.
Technical Specifications
Lock Mortise Upcut Tool R60-01742
- Royce Ayr
- 3-Flute Lock Mortise Upcut Tool
- R60-01742
- Lock Mortise Tool Upcut
- CNC Router
- 0.5000 in / 1/2 in (12.7 mm)
- 1.500 in / 1-1/2 in (38.1 mm)
- 1.500 in / 1-1/2 in (38.1 mm)
- 4.500 in / 4-1/2 in (114.3 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 6.000 in / 6 in (152.4 mm)
- 3
- Cut Direction: Upcut · Cutting Geometry: Lock Mortise Geometry with Serrated Tooth Design and Spinback Relief · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Primary Application: Mortising the Side of Doors to Hold Lock Sets · Industry Suitability: Window & Door; Moulding & Millwork; Stairs & Railings · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders and RH Rotation
- Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly, right-hand spindle rotation, and sufficient reach and clearance for the 6-inch overall length.
Best Fit Applications
Deep CNC Door Mortising
Lock-Set Pocket Machining
Window & Door Production
Moulding & Millwork
Stair & Railing Components
Product Highlights
Spinback Relief
The spinback relief provides clearance for deep mortise cutting and supports the extended reach required in door-lock machining.
Extended 6-Inch Format
The 1/2-inch diameter and shank, 1-1/2-inch cutting edge, and 6-inch overall length suit compatible deep-mortising CNC setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and support right-hand rotation. Verify collet condition, runout, safe toolholder engagement, projection, clearance for the 6-inch overall length, programmed mortise depth, pass strategy, RPM, feed speed, door material, guarding, dust extraction, and fixture or hold-down method. This is the uncoated configuration; verify the separately listed Ultimax-coated option when coating is required.
Improve Deep Door Mortising
The Royce Ayr 3-Flute Lock Mortise Upcut Tool R60-01742 provides an uncoated HW solid-carbide solution for accurate, repeatable CNC routing of deep lock-set pockets in the sides of doors.
Its 1/2-inch cutting diameter and shank, 1-1/2-inch cutting edge, serrated tooth design, spinback relief, right-hand upcut geometry, and 6-inch overall length support extended-reach mortising when correctly held and operated.
