High-Helix Upcut Geometry
The upcut geometry helps pull chips upward and away from the cut path where efficient evacuation is important.
Royce Ayr High Helix Ripper Upcut Router Bit — 1/2" (12.7mm)
CA$233.85
In stock
SKU
R60-01704
Product Type
3 Flute High Helix Ripper Upcut Router Bit
Series
High Helix Ripper Upcut
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-5/8 in (41.28 mm)
Shank
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Wood,Wood Composites,Fiberboard,Suitable Plastics
3-Flute Upcut High Helix
Ripper Router Bit
Upcut High Helix Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute high-helix upcut ripper router bit designed for CNC routing where chip evacuation, roughing performance, and reduced cutting load are important. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching 1/2-inch shank, and 4-inch overall length support deeper production routing in wood, wood composites, fiberboard, and suitable plastics.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4 in101.6 mm Overall Length
Upcut High Helix Ripper Bit
This production tool combines HW solid-carbide construction, three high-helix upcut flutes, right-hand rotation, and serrated ripper tooth geometry to support chip evacuation and controlled cutting through difficult wood grain.
HW / Solid Carbide3 FlutesRH High Helix UpcutSKU R60-01704
Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 3-Flute Upcut High Helix Ripper Router Bit R60-01704 is designed for CNC routing applications where chip evacuation and roughing performance matter. Its serrated tooth design is intended to reduce tear-out in difficult wood grains while lowering the horsepower required to cut.
The high-helix upcut geometry helps pull chips upward and away from the cut path, supporting deeper routing passes and production machining where heat and chip buildup must be controlled. The 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching 1/2-inch shank, and 4-inch overall length provide added reach for compatible CNC router setups.
This uncoated HW solid-carbide tool uses three high-helix upcut flutes and right-hand rotation. It is listed for routing wood, wood composites, fiberboard, and suitable plastics when correctly matched to the machine, collet, material, programmed depth, feed speed, RPM, chip extraction, and hold-down system. RPM/feed data and country of origin are not specified by the supplied source.
Technical Specifications
High-Helix Upcut Ripper Bit R60-01704
- Royce Ayr
- 3-Flute Upcut High Helix Ripper Router Bit
- R60-01704
- High Helix Ripper Upcut
- CNC Router
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.28 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Upcut
- High Helix
- Tooth Design: Serrated Ripper-Style Tooth Design · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Material Compatibility: Wood, Wood Composites, Fiberboard, and Suitable Plastics · Primary Applications: CNC Routing, Roughing, Chip Evacuation, Deeper Passes, Nested Machining, and Production Material Removal · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders and RH Rotation
- Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Best Fit Applications
Wood Routing & Roughing
Wood Composite Machining
Fiberboard Routing
Suitable Plastic Routing
Deeper CNC Chip Evacuation
Product Highlights
Serrated Ripper Tooth Design
The serrated tooth form is intended to reduce tear-out in difficult wood grains while lowering cutting horsepower demand.
Extended 1/2-Inch Format
The 1/2-inch diameter and shank, 1-5/8-inch cutting edge, and 4-inch overall length support deeper production routing.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and support right-hand rotation. Verify collet condition, runout, tool projection, available clearance, programmed cutting depth, RPM, feed speed, chipload, material suitability, workholding, guarding, and dust or chip extraction. Because this is an upcut tool, confirm that upward cutting action is appropriate for the required top-edge finish and part-hold-down strategy. Test plastics and composites under the actual machine conditions before production.
Improve Extended-Reach Upcut Routing
The Royce Ayr 3-Flute Upcut High Helix Ripper Router Bit R60-01704 provides an uncoated HW solid-carbide solution for CNC routing where chip evacuation, roughing efficiency, and controlled cutting matter.
Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching shank, three-flute high-helix upcut geometry, right-hand rotation, and 4-inch overall length support deeper production machining when correctly held and operated.
