Upcut Chip Evacuation
The upcut configuration helps pull chips out of the cut during routing operations where chip flow, heat control, and tool performance matter.
Royce Ayr 3-Flute Upcut Low Helix Ripper Router Bit 1/2" (12.7mm) – Right-Hand – 1-1/8"
CA$209.85
In stock
SKU
R60-01602
Product Type
3-Flute Upcut Low Helix Ripper Router Bit
Series
Low Helix Ripper Upcut
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3-1/2 in (88.9 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Difficult Wood Grain,Chip-Evacuation CNC Routing
3-Flute Upcut Low Helix
Ripper Router Bit
Upcut Low Helix Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute upcut low-helix ripper router bit designed for CNC routing where chip evacuation, controlled roughing, and reduced tear-out in difficult wood grains are important. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching 1/2-inch shank, and 3-1/2-inch overall length support millwork, construction-related wood components, stair and railing parts, pocketing, dado-style cuts, and general production routing.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Upcut Low Helix Ripper Bit
This production tool combines HW solid-carbide construction, three low-helix upcut flutes, right-hand rotation, and serrated ripper tooth geometry to support chip evacuation and controlled cutting through difficult wood grain.
HW / Solid Carbide3 FlutesRH Low Helix UpcutSKU R60-01602
Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 3-Flute Upcut Low Helix Ripper Router Bit R60-01602 is designed for CNC router work where efficient roughing, chip evacuation, and controlled cutting through difficult wood grain are required. Its serrated tooth design helps manage tear-out in challenging grain conditions while reducing the horsepower required to cut compared with conventional continuous-edge geometry.
The upcut configuration helps pull chips out of the cut, making this tool a practical choice for routing operations where chip flow matters. The 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching 1/2-inch shank, and 3-1/2-inch overall length provide a common production format for compatible CNC router collets and toolholders.
This uncoated HW solid-carbide tool uses three low-helix upcut flutes and right-hand rotation. It is suited to millwork, construction-related wood components, stairs, railings, and other routing operations where a serrated upcut ripper is preferred over a standard finish spiral. RPM, feed data, and country of origin are not specified by the supplied source.
Technical Specifications
Low-Helix Upcut Ripper Bit R60-01602
- Royce Ayr
- 3-Flute Upcut Low Helix Ripper Router Bit
- R60-01602
- Low Helix Ripper Upcut
- CNC Router
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.58 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.500 in / 3-1/2 in (88.9 mm)
- 3
- Upcut
- Low Helix
- Tooth Design: Serrated Ripper-Style Tooth Design · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Material Compatibility: Difficult Wood Grains and Compatible Wood Applications · Listed Industries: Moulding & Millwork; Construction Industry; Stairs & Railings · Primary Applications: CNC Routing, Chip Evacuation, Roughing, Ripping, Pocketing, Dado-Style Work, and Production Wood Machining
- Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Best Fit Applications
Difficult Wood Grain Routing
Millwork & Moulding Production
Stair & Railing Components
Pocketing & Dado-Style Cuts
Upcut Chip Evacuation
Product Highlights
Serrated Low-Helix Ripper
The serrated tooth geometry helps manage tear-out in difficult wood grain while reducing cutting horsepower demand.
1/2-Inch CNC Format
The 1/2-inch cutting diameter and shank with a 1-1/8-inch cutting edge fit common compatible CNC router tooling setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and support right-hand rotation. Verify collet condition, runout, tool projection, available clearance, programmed cutting depth, RPM, feed speed, chipload, material suitability, hold-down method, guarding, and dust or chip extraction. Because this is an upcut tool, confirm that upward cutting action is suitable for the required top-edge finish and part-hold-down strategy.
Improve 1/2-Inch Upcut Ripping
The Royce Ayr 3-Flute Upcut Low Helix Ripper Router Bit R60-01602 provides an uncoated HW solid-carbide solution for CNC routing where chip evacuation and controlled cutting in difficult wood grain matter.
Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching shank, three-flute low-helix upcut geometry, right-hand rotation, and 3-1/2-inch overall length support production machining when correctly held and operated.
