High-Helix Downcut Ripping
The downcut geometry directs cutting pressure toward the table to support part stability during heavier compatible routing operations.
Royce Ayr 3-Flute Downcut High Helix Ripper 5/8" (15.88mm)
CA$428.55
In stock
SKU
R60-01506
Product Type
3-Flute Downcut High Helix Ripper
Series
High Helix Ripper Downcut
Cutting Diameter
5/8 in (15.88 mm)
Cutting Edge
2-1/8 in (53.98 mm)
Shank
5/8 in (15.88 mm)
Overall Length
5 in (127 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Wood,Wood-Composite,Downcut CNC Routing
3-Flute Downcut High Helix
Ripper Router Bit
High-Helix Downcut Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute high-helix downcut ripper router bit designed for production CNC routing where aggressive material removal must be balanced with edge control, material hold-down, and reduced tear-out. Its 5/8-inch cutting diameter, 2-1/8-inch cutting edge, matching 5/8-inch shank, and 5-inch overall length support heavier routing in solid wood, wood composites, cabinet parts, millwork, fixtures, and compatible woodworking applications.
D=5/8 in15.88 mm Diameter
CE=2-1/8 in53.98 mm Cutting Edge
Sh=5/8 in15.88 mm Shank
OAL=5 in127 mm Overall Length
High-Helix Downcut Ripper Bit
This heavier production tool combines HW solid-carbide construction, three high-helix downcut flutes, right-hand rotation, and serrated ripper tooth geometry to help reduce tear-out while supporting part hold-down.
HW / Solid Carbide3 FlutesRH High Helix DowncutSKU R60-01506
Designed for compatible CNC routers using a precision 5/8-inch collet or approved toolholding assembly with right-hand spindle rotation and adequate clearance for the 5-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01506 is designed for production routing where aggressive material removal must be balanced with edge control. Its downcut geometry directs cutting pressure toward the table, supporting part hold-down and helping reduce lifting on nested or vacuum-held workpieces.
The serrated tooth design is intended to reduce tear-out in difficult wood grains while lowering horsepower demand compared with a conventional smooth cutting edge. This makes the tool a practical option for CNC shops machining solid wood, wood composites, and other supported woodworking materials where chip control, hold-down, and dependable roughing performance matter.
This uncoated HW solid-carbide tool uses three high-helix downcut flutes and right-hand rotation. Its 5/8-inch cutting diameter, 2-1/8-inch cutting edge, matching 5/8-inch shank, and 5-inch overall length suit heavier compatible CNC routing setups. RPM, feed data, and country of origin are not specified by the supplied source and should be confirmed when required.
Technical Specifications
High-Helix Ripper Bit R60-01506
- Royce Ayr
- 3-Flute Downcut High Helix Ripper Router Bit
- R60-01506
- High Helix Ripper Downcut
- 0.6250 in / 5/8 in (15.88 mm)
- 2.125 in / 2-1/8 in (53.98 mm)
- 0.625 in / 5/8 in (15.88 mm)
- 5.000 in / 5 in (127 mm)
- 3
- Downcut
- High Helix
- Serrated Ripper-Style Tooth Design
- Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Material Compatibility: Solid Wood, Wood Composites, and Compatible Woodworking Materials · Primary Applications: CNC Routing, Roughing, Profiling, Tear-Out Control, Material Hold-Down, and Production Material Removal · Machine Interface: CNC Routers with Compatible 5/8-Inch Collets or Toolholders and RH Rotation
- Designed for compatible CNC routers using a precision 5/8-inch collet or approved toolholding assembly with right-hand spindle rotation and adequate clearance for the 5-inch overall length.
Best Fit Applications
Solid Wood Roughing
Wood Composite Machining
Difficult Grain Routing
Nested Panel Hold-Down
Cabinet & Millwork Production
Product Highlights
Serrated Tooth Design
The serrated ripper tooth form is intended to reduce tear-out in difficult wood grains while lowering cutting horsepower demand.
Heavy 5/8-Inch Format
The 5/8-inch diameter and shank, 2-1/8-inch cutting edge, and 5-inch overall length support compatible larger-format CNC routing.
Compatibility & Installation Notes
Confirm that the machine spindle, collet, and toolholder accept an exact 5/8-inch (15.88 mm) shank and support right-hand rotation. Verify clearance for the 5-inch overall length, tool projection, programmed cutting depth, RPM, feed speed, chipload, material suitability, spoilboard or vacuum hold-down, guarding, and dust or chip extraction before production. Downcut tools can support top-edge control and hold-down, but chip evacuation and heat must be managed correctly.
Improve Heavy Downcut Ripping
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01506 provides an uncoated HW solid-carbide solution for heavier CNC routing where tear-out control, part stability, and material hold-down matter.
Its 5/8-inch cutting diameter, 2-1/8-inch cutting edge, matching shank, three-flute high-helix downcut geometry, right-hand rotation, and 5-inch overall length support demanding production machining when correctly held and operated.
