Serrated Downcut Geometry
The serrated tooth design is intended to reduce tear-out while lowering the horsepower required to cut.
Royce Ayr 3-Flute High-Helix Downcut Ripper Bit 1/2" (12.7mm)
CA$233.85
In stock
SKU
R60-01504
Product Type
High-Helix Downcut Ripper Router Bit
Series
High-Helix Ripper Downcut
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-5/8 in (41.28 mm)
Shank
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
CNC Routing,Downcut Ripping,Difficult Wood Grains
3-Flute Downcut High Helix
Ripper Router Bit
High-Helix Downcut Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute high-helix downcut ripper router bit designed for CNC routing where material hold-down, top-edge control, and reduced tear-out in difficult wood grains are important. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching 1/2-inch shank, and 4-inch overall length support deeper routing, roughing, ripping, profiling, and material-removal operations.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4 in101.6 mm Overall Length
High-Helix Downcut Ripper Bit
This production tool combines HW solid-carbide construction, three high-helix downcut flutes, right-hand rotation, and serrated ripper tooth geometry to help reduce tear-out while supporting material hold-down.
HW / Solid Carbide3 FlutesRH High Helix DowncutSKU R60-01504
Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01504 is designed for CNC routing where the tool must control surface tear-out while helping keep the material pressed toward the table during cutting. It is part of the High-Helix Ripper Downcut series within Royce Ayr solid-carbide CNC tooling.
The serrated tooth geometry is intended to reduce tear-out in difficult wood grains while lowering the horsepower required to cut compared with a conventional smooth-edge tool. The downcut design directs cutting force toward the table, making this bit useful when top-edge quality and material hold-down are important considerations.
The 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching 1/2-inch shank, three-flute configuration, right-hand rotation, and 4-inch overall length provide added reach for compatible CNC routing setups. This uncoated HW solid-carbide tool must be matched to the machine spindle, collet, toolholder, programmed feed and speed, cutting depth, workholding, and actual material being machined.
Technical Specifications
High-Helix Ripper Bit R60-01504
- Royce Ayr
- 3-Flute Downcut High Helix Ripper Router Bit
- R60-01504
- High-Helix Ripper Downcut
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.28 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Downcut
- High Helix
- Serrated Tooth Design
- Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Material Compatibility: Difficult Wood Grains and Compatible Wood Applications · Primary Applications: CNC Routing, Downcut Ripping, Roughing, Tear-Out Control, Material Hold-Down, Profiles, and Material Removal · Machine Interface: CNC Routers and Routing Equipment with Compatible 1/2-Inch Toolholding and RH Rotation
- Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Best Fit Applications
Difficult Wood Grain Routing
Downcut Material Hold-Down
Roughing & Ripping Passes
Deeper Profile Routing
Production Material Removal
Product Highlights
Material Hold-Down Support
The downcut design directs cutting force toward the table when top-edge quality and workpiece control are priorities.
Longer 1-5/8-Inch Reach
The verified cutting edge and 4-inch overall length support deeper routing operations in properly matched CNC setups.
Compatibility & Installation Notes
Confirm that the machine spindle, toolholder, and collet accept an exact 1/2-inch (12.7 mm) shank and support right-hand rotation. Verify available clearance, tool projection, programmed cutting depth, and whether the 1-5/8-inch cutting edge is appropriate for the part thickness and cutting strategy. Match RPM, feed speed, chipload, hold-down method, guarding, dust or chip extraction, and material suitability to the actual operation.
Improve Longer-Reach Downcut Ripping
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01504 provides an uncoated HW solid-carbide solution for CNC routing that requires material hold-down and improved control of tear-out in difficult wood grains.
Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, matching shank, three-flute high-helix downcut geometry, right-hand rotation, and 4-inch overall length support controlled production machining when correctly held and operated.
