Downcut Material Control
The downcut geometry directs cutting pressure toward the table or spoilboard to help support the workpiece during routing.
Royce Ayr 3 Flute Downcut Low Helix Ripper 5/8" (15.88mm)
CA$458.10
In stock
SKU
R60-01406
Product Type
3 Flute Downcut Low Helix Ripper
Series
R60 Industrial Routing / Low Helix Ripper
Cutting Diameter
5/8 in (15.88 mm)
Cutting Edge
2-1/8 in (53.98 mm)
Shank
5/8 in (15.88 mm)
Overall Length
5 in (127 mm)
Flutes
3
Cut Direction
Downcut
Helix
Low Helix
Tooth Design
Serrated Tooth Design
Application
Difficult Wood Grains,Downcut Material Hold-Down
3-Flute
Downcut Low-Helix
Ripper Router Bit
Heavy-duty solid-carbide downcut low-helix ripper designed for industrial CNC routing in difficult wood grain. Its 5/8-inch cutting diameter, 2-1/8-inch cutting edge, 5/8-inch shank, serrated tooth form, and 5-inch overall length support demanding production cuts where material control and tear-out reduction are priorities.
D=5/8 in15.88 mm Diameter
CE=2-1/8 in53.98 mm Cutting Edge
Sh=5/8 in15.88 mm Shank
OAL=5 in127 mm Overall Length
Downcut Low-Helix Ripper
This production tool combines HW solid-carbide construction, three right-hand downcut flutes, a low-helix configuration, and a serrated tooth design for controlled routing in challenging wood grain.
HW / Solid Carbide3 FlutesRH DowncutSKU R60-01406
Designed for compatible CNC routers and industrial routing systems using precision 5/8-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 3-Flute Downcut Low-Helix Ripper Router Bit R60-01406 is designed for CNC and industrial routing applications where difficult wood grain, material control, and tear-out reduction are important. Its downcut geometry directs cutting pressure toward the table or spoilboard, helping support the workpiece during machining.
The serrated tooth design is intended to reduce tear-out in challenging grain while lowering the horsepower required to cut. A 0.6250-inch cutting diameter, 2.125-inch cutting edge, and three-flute low-helix configuration provide a heavy production format for roughing, ripping, profiling, and deeper routing passes.
This uncoated HW solid-carbide tool uses right-hand rotation, a 0.625-inch shank, and a 5.000-inch overall length. Correct collet condition, minimum practical projection, verified runout, suitable spindle capacity, RPM, feed rate, depth-per-pass, workholding, clearance, and chip evacuation are essential for maintaining dimensional control and tool life.
Technical Specifications
Low-Helix Ripper R60-01406
- Royce Ayr
- 3-Flute Downcut Low-Helix Ripper Router Bit
- R60-01406
- R60 Low Helix Ripper Downcut
- HW / Solid Carbide CNC Router Tooling
- 0.6250 in / 5/8 in (15.88 mm)
- 2.125 in / 2-1/8 in (53.98 mm)
- 0.625 in / 5/8 in (15.88 mm)
- 5.000 in / 5 in (127 mm)
- 3
- RH / Right Hand
- HW / Solid Carbide · Downcut Low Helix Ripper · Uncoated
- Difficult Wood Grain and Production Wood Routing
- CNC Routers with Precision 5/8-Inch Collets
Best Fit Applications
Difficult Wood-Grain Routing
Industrial Roughing & Ripping
Downcut Material Control
Cabinet & Millwork CNC
Heavy Production Profiling
Product Highlights
Serrated Ripper Tooth Form
The serrated design is intended to reduce tear-out in difficult wood grain while lowering the horsepower required to cut.
Heavy 5/8-Inch Format
The 5/8-inch diameter, 2-1/8-inch cutting edge, matching shank, and 5-inch overall length support demanding production routing.
Compatibility & Installation Notes
Confirm that the spindle and toolholder accept an exact 5/8-inch (15.88 mm) shank and provide sufficient clearance for the 5-inch overall length and required projection. Inspect and clean the collet, collet nut, and tool shank, minimize unsupported projection, verify runout, and confirm right-hand rotation before machining. Match spindle capacity, RPM, feed rate, depth-per-pass, workholding, guarding, and chip evacuation to the selected wood material and machine conditions.
Control Heavy Downcut Routing
The Royce Ayr 3-Flute Downcut Low-Helix Ripper Router Bit R60-01406 provides a rigid HW solid-carbide solution for demanding CNC routing in difficult wood grain.
Its serrated tooth form, 5/8-inch diameter, 2-1/8-inch cutting edge, matching shank, three-flute geometry, and 5-inch overall length support controlled production cutting when correctly held and operated.
