Working geometry
The interrupted cutting geometry breaks the cut into smaller sections.
Royce Ayr R60-01404 - Solid Carbide Low Helix Ripper Downcut Router Bit - 1/2 in Dia x 1-5/8 in Cut x RH
CA$252.90
In stock
SKU
R60-01404
Product Type
Solid Carbide Low Helix Ripper Downcut Router Bit
Cutting Material
Solid Carbide
Cutting Diameter
1/2 in (12.7 mm)
Cutting Length
1-5/8 in (41.275 mm)
Shank Diameter
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flute Count
3
Rotation
Right Hand
Cut Direction
Downcut
Coating
None
Machine Type
CNC router
Solid Carbide Low Helix Ripper Downcut Router Bit
Royce Ayr
R60-01404
Designed to remove stock before finishing.
1/2 in (12.7 mm)Cutting Diameter
1-5/8 in (41.275 mm)Cutting Length
1/2 in (12.7 mm)Shank Diameter
4 in (101.6 mm)Overall Length
Solid Carbide Low Helix Ripper Downcut Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid CarbideDowncutRight HandSKU R60-01404
Choose a holder or collet for the 1/2 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide low helix ripper downcut router bit is designed to remove stock before finishing. It is suitable for wood.
The interrupted cutting geometry breaks the cut into smaller sections. Use it for stock removal and allow a separate finishing pass when the final edge requires one. The downcut geometry shears toward the workpiece, helping support the top edge during the pass. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/2 in cutting diameter and 1-5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Technical Specifications
R60-01404 · Solid Carbide Low Helix Ripper Downcut Router Bit
- Royce Ayr
- R60-01404
- Solid Carbide Low Helix Ripper Downcut Router Bit
- Low Helix Ripper Downcut
- Solid Carbide
- 1/2 in (12.7 mm)
- 1-5/8 in (41.275 mm)
- 1/2 in (12.7 mm)
- 4 in (101.6 mm)
- 3
- Right Hand
- Downcut
- None
- CNC router
Tool Configuration
rough routing wood
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 1/2 in cutting diameter and 1-5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Use only with right hand spindle operation and compatible toolholding.
Solid Carbide Low Helix Ripper Downcut Router Bit
Royce Ayr R60-01404 is designed to remove stock before finishing. It is suitable for wood.
The interrupted cutting geometry breaks the cut into smaller sections. Use it for stock removal and allow a separate finishing pass when the final edge requires one. The downcut geometry shears toward the workpiece, helping support the top edge during the pass. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/2 in cutting diameter and 1-5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
