Downcut Hold-Down Support
The downcut geometry directs cutting pressure into the workpiece to support material hold-down during compatible CNC routing operations.
Royce Ayr 3 Flute Downcut Low Helix Ripper 1/2" (12.7mm) – 3-Flute – 1-1/8"
CA$209.85
In stock
SKU
R60-01402
Product Type
3 Flute Downcut Low Helix Ripper Router Bit
Series
R60-014 Downcut Low Helix Ripper
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3-1/2 in (88.9 mm)
Flutes
3
Cut Direction
Downcut
Helix
Low Helix
Tooth Style
Serrated Tooth / Ripper Style
Application
Difficult Wood Grains,Downcut Material Hold-Down
3-Flute
Downcut Low Helix
Ripper Router Bit
Solid-carbide 3-flute downcut low helix ripper router bit designed for CNC routing where material hold-down, tear-out control, and efficient roughing are important. Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching 1/2-inch shank, and 3-1/2-inch overall length support difficult wood grains, wood-based parts, cabinet components, millwork, furniture production, and panel-processing applications.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Downcut Low Helix Ripper Bit
This production tool combines solid-carbide construction, three downcut low-helix flutes, and a serrated ripper-style tooth design to help reduce tear-out while directing cutting pressure into the workpiece.
Solid Carbide3 FlutesLow Helix DowncutSKU R60-01402
Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with suitable spindle direction, chip evacuation, and workholding.
Main Product Description
The Royce Ayr 3-Flute Downcut Low Helix Ripper Router Bit R60-01402 is designed for CNC routing and industrial woodworking applications where hold-down, edge control, and roughing efficiency matter. Its downcut geometry directs cutting pressure into the workpiece, helping support material hold-down during compatible routing operations.
The serrated ripper-style tooth form is intended to reduce tear-out in difficult wood grains and lower cutting horsepower requirements compared with a smoother continuous-edge format. The 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching 1/2-inch shank, and 3-1/2-inch overall length provide a compact production format for compatible CNC router collets and toolholders.
This solid-carbide tool uses three downcut low-helix flutes. Rotation, coating, RPM or feed data, and country of origin are not specified by the supplied source and should be confirmed before ordering, programming, or installation. Correct collet condition, minimum practical projection, verified runout, suitable chipload, pass depth, workholding, guarding, and dust or chip evacuation remain essential.
Technical Specifications
Low Helix Ripper Bit R60-01402
- Royce Ayr
- 3-Flute Downcut Low Helix Ripper Router Bit
- R60-01402
- R60-014 Downcut Low Helix Ripper
- Solid Carbide CNC Router Tooling
- 1/2 in (12.7 mm)
- 1-1/8 in (28.58 mm)
- 1/2 in (12.7 mm)
- 3-1/2 in (88.9 mm)
- 3
- Not Specified by Supplied Source
- Solid Carbide · Downcut
- Difficult Wood Grains and Wood-Based Materials
- CNC Routers with Compatible 1/2-Inch Collets or Toolholders
Best Fit Applications
Difficult Wood Grain Routing
Roughing & Ripping Passes
Material Hold-Down Routing
Cabinet & Millwork Production
Furniture & Panel Processing
Product Highlights
Serrated Ripper Tooth Design
The serrated ripper-style tooth form is intended to reduce tear-out in difficult wood grains and lower cutting horsepower requirements.
1/2-Inch Production Format
The matching cutting diameter and shank suit common industrial CNC router setups requiring a compact downcut ripper tool.
Compatibility & Installation Notes
Confirm that the spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and provide adequate clearance for the 3-1/2-inch overall length and required projection. Rotation, coating, and RPM or feed data are not specified by the supplied source, so verify those details before ordering or programming. Confirm that downcut geometry and chip evacuation are suitable for the material, and match chipload, pass depth, workholding, guarding, and dust collection to the operation.
Improve Downcut Ripper Performance
The Royce Ayr 3-Flute Downcut Low Helix Ripper Router Bit R60-01402 provides a solid-carbide solution for difficult wood grains and wood-based production routing where material hold-down and tear-out control matter.
Its 1/2-inch cutting diameter, 1-1/8-inch cutting edge, matching shank, three-flute low-helix downcut geometry, serrated tooth form, and 3-1/2-inch overall length support controlled CNC routing when correctly held and operated.
