Working geometry
Use the cutter for the final pass that establishes the finished edge.
Royce Ayr Solid Carbide Low Helix Upcut Router Bit - 3/4" Diameter x 2-1/8" Cut
CA$526.75
In stock
SKU
R60-22512
Product Type
3-Flute Low Helix Up-Cut Router Bit
Diameter
3/4 in (19.05 mm)
Cutting Edge
2-1/8 in (54.0 mm)
Shank
3/4 in (19.05 mm)
Overall Length
5 in (127.0 mm)
Application
Deep Production Nesting,Thick Panel Milling
3-Flute Upcut Low Helix
Finisher Router Bit
Upcut Low Helix Finisher
Designed to finish routed edges and contours.
D=3/4 in19.05 mm Diameter
CE=2-1/8 in53.975 mm Cutting Edge
Sh=3/4 in19.05 mm Shank
OAL=5 in127 mm Overall Length
Upcut Low Helix Finisher
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid Carbide / HW3 FlutesLow Helix UpcutSKU R60-22512
Choose a holder or collet for the 3/4 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide low helix upcut finisher is designed to finish routed edges and contours. It is suitable for plastics, composites and solid wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/4 in cutting diameter and 2-1/8 in cutting length define the working section of this version. Its 3/4 in shank fits a holder or collet matched to that diameter.
Technical Specifications
Low Helix Finisher Upcut R60-22512
- Royce Ayr
- 3-Flute Upcut Low Helix Finisher Router Bit
- R60-22512
- Low Helix Finisher Upcut
- HW / Solid Carbide
- 0.7500 in / 3/4 in (19.05 mm)
- 2.125 in / 2-1/8 in (53.975 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 5.000 in / 5 in (127 mm)
- 3
- Low Helix Upcut Finisher
- RH / Right Hand
- Coating: None · Construction: HW / Solid Carbide · Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 3/4-inch (19.05 mm) collet or approved toolholding system with sufficient clearance for the 5-inch overall length.
Best Fit Applications
Plastic Finishing
Composite Routing
Solid-Wood Finish Passes
Extended-Reach Machining
Upcut Chip Evacuation
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 3/4 in cutting diameter and 2-1/8 in cutting length define the working section of this version. Its 3/4 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm toolholding for the shank size 0.750" and right-hand spindle operation. Secure the workpiece against lift from the upcut action. Confirm the exact plastic or composite and cutting conditions. Match the tool to the specific material grade and cutting conditions.
Extend Finishing Reach with Controlled Upcut Geometry
Royce Ayr R60-22512 is designed to finish routed edges and contours. It is suitable for plastics, composites and solid wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/4 in cutting diameter and 2-1/8 in cutting length define the working section of this version. Its 3/4 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
