Low-Helix Finishing Geometry
Low-helix flute geometry supports controlled finishing passes in compatible plastics, composites, and solid wood.
Royce Ayr Solid Carbide Low Helix Upcut Router Bit - 1/2" Diameter x 2-1/8" Cut
CA$262.65
In stock
SKU
R60-22510
Product Type
3-Flute Low Helix Up-Cut Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
2-1/8 in (54.0 mm)
Shank
1/2 in (12.7 mm)
Geometry
3 Flutes / Up-Cut / Low Helix
Application
Aggressive Chip Evacuation,Nesting,Sizing,Finishing
3-Flute Upcut Low Helix
Finisher Router Bit
Upcut Low Helix Finisher
Solid-carbide low-helix upcut finisher for routing plastics and composites and for finish passes in solid wood. Its 1/2-inch cutting diameter, 2-1/8-inch cutting edge, 1/2-inch shank, three-flute geometry, and 4-inch overall length support extended finishing cuts with upward chip evacuation.
D=1/2 in12.7 mm Diameter
CE=2-1/8 in53.975 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4 in101.6 mm Overall Length
Upcut Low Helix Finisher
This three-flute solid-carbide tool uses low-helix upcut geometry for controlled finishing in plastics, composites, and solid wood while directing chips upward from the cutting path.
Solid Carbide / HW3 FlutesLow Helix UpcutSKU R60-22510
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Upcut Low Helix Finisher Router Bit R60-22510 is part of Royce Ayr's Low Helix Finisher Upcut series. It is intended for routing plastics and composites and for finish passes in solid wood.
The upcut flute direction moves chips upward from the cut, while the low-helix finishing geometry supports controlled material engagement and surface quality in compatible applications. The three-flute format is suited to production finishing when feed rate, spindle speed, and chip load are correctly matched.
The 0.5000-inch cutting diameter, 2.125-inch cutting edge, 0.500-inch shank, and 4.000-inch overall length require rigid, low-runout toolholding and adequate machine clearance. Before machining, verify collet condition, right-hand spindle rotation, tool projection, feed rate, spindle speed, depth per pass, workholding, and chip extraction.
Technical Specifications
Low Helix Finisher Upcut R60-22510
- Royce Ayr
- 3-Flute Upcut Low Helix Finisher Router Bit
- R60-22510
- Low Helix Finisher Upcut
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 2.125 in / 2-1/8 in (53.975 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Low Helix Upcut Finisher
- RH / Right Hand
- Construction: HW / Solid Carbide · Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Best Fit Applications
Plastic Finishing
Composite Routing
Solid-Wood Finish Passes
Extended-Depth Machining
Upcut Chip Evacuation
Product Highlights
Upcut Chip Direction
Upcut action directs chips upward from the cutting path to support evacuation during extended cutting operations.
Extended 2-1/8-Inch Cutting Edge
The 2-1/8-inch cutting edge provides additional reach for compatible CNC finishing and profile-routing applications.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 4-inch (101.6 mm) overall length. Use rigid, low-runout toolholding, minimize unsupported projection where possible, verify right-hand rotation, and establish suitable spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being machined.
Extend Finishing Reach with Controlled Upcut Geometry
The Royce Ayr 3-Flute Upcut Low Helix Finisher Router Bit R60-22510 provides a solid-carbide solution for routing plastics and composites and for finish passes in solid wood.
Its 1/2-inch diameter and shank, 2-1/8-inch cutting edge, three-flute low-helix geometry, and 4-inch overall length suit compatible CNC systems when the tool is correctly held and operated within appropriate machining parameters.
