Chip-Breaker Harmonic Control
Specialized chip-breaker geometry is intended to help reduce harmonics during routing of phenolic and fiber-reinforced plastic materials.
Royce Ayr 3-Flute Solid Carbide Low Helix Upcut Router Bit - 1/2" Diameter x 1-1/4" Cut
CA$237.75
In stock
SKU
R72-10007
Product Type
3 Flute Low Helix Up Cut Bit
Diameter
1/2 in (12.7 mm)
Cutting Length
1-1/4 in (31.75 mm)
Overall Length
3-1/2 in (88.9 mm)
Flutes
3
Material
Solid Carbide
Application
Phenolic,Plastics,Composites,High-Density Materials
3-Flute Low-Helix Upcut
Phenolic Router Bit
Phenolic & Composite Upcut Bit
Solid-carbide, right-hand, three-flute low-helix upcut router bit designed for phenolic and other fiber-reinforced plastics. Its 1/2-inch cutting diameter, 1-1/4-inch cutting edge, 1/2-inch shank, and 3-inch overall length combine with chip-breaker geometry to help control harmonics and support efficient chip evacuation in compatible CNC routing applications.
D=1/2 in12.7 mm Diameter
CE=1-1/4 in31.75 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3 in76.2 mm Overall Length
Phenolic & Composite Upcut Bit
This three-flute solid-carbide tool combines low-helix upcut geometry with specialized chip-breakers intended to help reduce harmonics while routing phenolic and fiber-reinforced plastics.
Solid Carbide / HW3 FlutesRight-HandSKU R72-10007
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding assembly with sufficient clearance for the 3-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Low-Helix Upcut Router Bit R72-10007 is engineered for routing phenolic and other fiber-reinforced plastics. Its 0.5000-inch cutting diameter and 1.250-inch cutting edge provide a practical production format for profiling, slotting, trimming, and controlled material removal in compatible composite-sheet applications.
The three-flute low-helix upcut geometry supports chip evacuation while maintaining stable cutting engagement. Royce Ayr specifies unique chip-breakers that help eliminate harmonics during routing, improving process stability when the tool is matched to suitable spindle speed, feed rate, and workholding.
The 0.500-inch shank and 3.000-inch overall length require a compatible precision collet or approved toolholder. Before production, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, material suitability, and chip or dust extraction.
Technical Specifications
Phenolic Upcut Router Bit R72-10007
- Royce Ayr
- 3-Flute Low-Helix Upcut Router Bit
- R72-10007
- Solid Carbide CNC Router Tooling
- Phenolic & Fiber-Reinforced Plastic Routing
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 1.250 in / 1-1/4 in (31.75 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 3
- Low-Helix Upcut with Chip-Breakers
- Rotation: RH / Right Hand · Coating: None · Material Compatibility: Phenolic and Other Fiber-Reinforced Plastics · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding assembly with sufficient clearance for the 3-inch overall length.
Best Fit Applications
Phenolic Sheet Routing
Fiber-Reinforced Plastics
Composite Panel Profiling
Slotting & Trimming
CNC Production Routing
Product Highlights
Three-Flute Low-Helix Geometry
The three-flute low-helix upcut form balances controlled cutting engagement with upward chip evacuation in compatible CNC applications.
Rigid 1/2-Inch Tool Format
The matching 1/2-inch cutting diameter and shank support secure precision toolholding and stable routing in properly configured systems.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, material suitability, and chip extraction according to the machine and approved shop procedures.
Improve Phenolic Routing Stability
The Royce Ayr 3-Flute Low-Helix Upcut Router Bit R72-10007 provides a solid-carbide solution for routing phenolic and other fiber-reinforced plastics. Its 1/2-inch diameter, 1-1/4-inch cutting edge, 1/2-inch shank, three-flute geometry, and 3-inch overall length support profiling, slotting, trimming, and production routing.
Low-helix upcut geometry supports chip evacuation, while the specialized chip-breakers help control harmonics when the tool is correctly held and operated within suitable machining parameters.
