Clean-Edge Downcut Action
Downcut geometry directs cutting force toward the work surface to support clean top edges in laminated routing applications.
Royce Ayr 3-Flute Solid Carbide Down-Cut Router Bit - 1/2" Chipbreaker
CA$237.40
In stock
SKU
R60-32004
Product Type
3 Flute Down-Cut Router Bit w/ Chipbreaker
Diameter
1/2 in (12.7 mm)
Cutting Edge
1-5/8 in (41.3 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3-1/2 in (88.9 mm)
Flute Geometry
3 Flutes / Down-Cut / Chipbreaker
Application
CNC Nesting,Cabinetry,Laminates,Melamine,Wood Veneers
3-Flute Downcut Chipbreaker
Finisher Router Bit
Downcut Chipbreaker Finisher
Solid-carbide downcut chipbreaker finisher designed for general-purpose routing in solid wood and wood composites. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 1/2-inch shank, three-flute geometry, and 3-1/2-inch overall length support productive profiling and dado routing while helping maintain a clean top edge in laminated material.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.275 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Downcut Chipbreaker Finisher
This three-flute solid-carbide tool combines downcut cutting action with chipbreaker geometry to support clean top edges, controlled chip formation, and productive routing in solid wood and wood composites.
Solid Carbide / HW3 FlutesDowncut ChipbreakerSKU R60-32004
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 3-1/2-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Downcut Chipbreaker Finisher Router Bit R60-32004 is designed for general-purpose routing in solid wood and wood composites. Its downcut geometry directs cutting force toward the work surface, helping produce a clean edge when cutting dados and profiles in laminated material.
Integrated chipbreaker geometry helps divide larger chips into smaller fragments, supporting smoother chip evacuation and helping reduce furring and tear-out in compatible materials. The three-flute format supports productive CNC routing when machine power, feed rate, spindle speed, and chip load are correctly matched.
The 0.5000-inch cutting diameter, 1.625-inch cutting edge, 0.500-inch shank, and 3.500-inch overall length require a compatible precision collet or approved toolholder. Before machining, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, and chip extraction.
Technical Specifications
Downcut Chipbreaker Finisher R60-32004
- Royce Ayr
- 3-Flute Downcut Chipbreaker Finisher Router Bit
- R60-32004
- 3 Flute Downcut Chipbreaker Finisher
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.275 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.500 in / 3-1/2 in (88.9 mm)
- 3
- Downcut Chipbreaker Finisher
- RH / Right Hand
- Construction: Solid Carbide · Material Compatibility: Solid Wood and Wood Composites · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 3-1/2-inch overall length.
Best Fit Applications
Solid-Wood Profiling
Wood-Composite Routing
Laminated Dado Cutting
Panel Edge Machining
Production CNC Routing
Product Highlights
Chipbreaker Geometry
Chipbreakers help divide larger chips and reduce furring and tear-out during compatible solid-wood and composite machining.
Production Tool Format
The 1/2-inch diameter and shank, 1-5/8-inch cutting edge, and 3-1/2-inch overall length suit compatible CNC routing.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-1/2-inch (88.9 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, and chip extraction for the solid-wood or wood-composite material being machined.
Improve Clean-Edge Production Routing
The Royce Ayr 3-Flute Downcut Chipbreaker Finisher Router Bit R60-32004 provides a solid-carbide solution for routing solid wood and wood composites. Its three-flute downcut chipbreaker geometry supports clean-edge dado and profile machining in laminated material.
The 1/2-inch diameter and shank, 1-5/8-inch cutting edge, and 3-1/2-inch overall length suit compatible CNC systems when the tool is correctly held and operated within appropriate feed, speed, workholding, and extraction parameters.
