Efficient Chip Evacuation
Upcut spiral geometry lifts chips from the cutting path to reduce recutting and support cleaner routing through deeper slots and profiles.
Royce Ayr 2-Flute Up-Cut Solid Carbide Router Bit - 1/4" Diameter x 1-1/8" Cut
CA$999.99
In stock
SKU
R52-22814
Product Type
2 Flute Up-Cut Spiral Router Bit
Diameter
1/4 in (6.35 mm)
Cutting Edge
1 1/8 in (28.58 mm)
Shank
1/4 in (6.35 mm)
Overall Length
3 in (76.2 mm)
Rotation
Left-Hand (LH)
Cutting Geometry
2 Flutes / Up-Cut Spiral
Construction
Solid Carbide Tooling Category
Application
General Woodworking,MDF,Laminates,Upward Chip Evacuation,CNC Machining
2-Flute Upcut Spiral
Router Bit
General-Purpose Upcut Spiral
Solid-carbide, right-hand general-purpose upcut spiral router bit designed for solid wood, wood composites, and compatible plastics. Its 1/4-inch cutting diameter, 1-1/8-inch cutting edge, 1/4-inch shank, and 3-inch overall length support efficient chip evacuation in routing, grooving, slotting, and profiling operations.
D=1/4 in6.35 mm Diameter
CE=1 1/8 in28.58 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=3 in76.2 mm Overall Length
General-Purpose Upcut Spiral
This production-grade tool combines a rigid solid-carbide body, two upcut spiral flutes, and right-hand rotation for general-purpose routing with effective chip evacuation in compatible CNC routing systems.
Solid Carbide2 FlutesRight-HandSKU R52-22814
Designed for compatible CNC routers and industrial routing equipment using precision 1/4-inch collets or approved toolholding systems.
Main Product Description
The Royce Ayr 2-Flute General-Purpose Upcut Spiral Router Bit R52-22814 is engineered for routing solid wood, wood composites, and compatible plastics. Its 0.2500-inch cutting diameter and 1.125-inch cutting edge provide a practical configuration for profiling, grooving, slotting, dado work, through-cutting, and cabinet-component machining.
The two-flute upcut spiral geometry lifts chips away from the cutting path to support efficient evacuation and reduce chip recutting during deeper passes. Its solid-carbide construction provides the rigidity and edge retention needed for repeatable production routing when spindle speed, feed rate, and depth-per-pass are correctly matched to the material.
The 3.000-inch overall length, 0.250-inch shank, and right-hand rotation are suited to compatible CNC routers and industrial routing systems. Correct collet condition, tool projection, runout control, workholding, and dust extraction are essential for maintaining cutting quality and service life.
Technical Specifications
Upcut Spiral R52-22814
- Royce Ayr
- 2-Flute General-Purpose Upcut Spiral Router Bit
- R52-22814
- General-Purpose Upcut Spiral
- 0.2500 in / 1/4 in (6.35 mm)
- 1.125 in / 1 1/8 in (28.58 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- RH / Right Hand
- None
- HW / Solid Carbide
- Material Compatibility: Solid Wood, Wood Composites, and Compatible Plastics · Machine Interface: CNC Routers and Routing Systems with 1/4-Inch Collets
- Designed for compatible CNC routers and industrial routing equipment using precision 1/4-inch collets or approved toolholding systems.
Best Fit Applications
Solid Wood Routing
Wood Composite Machining
Grooving & Slotting
Profile & Through Cutting
Compatible Plastic Routing
Product Highlights
1-1/8-Inch Cutting Edge
The extended cutting edge supports deeper routing, grooving, and profiling operations while the solid-carbide body helps control deflection.
Right-Hand Two-Flute Geometry
Two cutting flutes and right-hand rotation provide a general-purpose configuration for repeatable CNC routing in compatible wood, composite, and plastic materials.
Compatibility & Installation Notes
Confirm that the spindle or router toolholder accepts an exact 1/4-inch (6.35 mm) shank and provides clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut for wear or contamination, minimize unsupported tool projection, and verify runout before machining. Because the upcut geometry applies upward axial force, use secure workholding and establish spindle speed, feed rate, and depth-per-pass according to the material and machine conditions.
Improve General-Purpose Routing Efficiency
The Royce Ayr 2-Flute General-Purpose Upcut Spiral Router Bit R52-22814 provides a solid-carbide solution for cabinet, furniture, panel, and architectural-millwork production. Its 1/4-inch diameter, 1-1/8-inch cutting edge, 1/4-inch shank, and 3-inch overall length support repeatable routing across solid wood, wood composites, and compatible plastics.
Right-hand, two-flute upcut geometry promotes effective chip evacuation and consistent cutting performance when the tool is correctly held and operated within suitable machining parameters.
