Working geometry
The cutting section follows the programmed path or guide to form the required shape.
Royce Ayr 2-Flute Upcut Solid Carbide Router Bit - 5/32" Diameter x 5/8" Cut
CA$55.45
In stock
SKU
R52-22804
Product Type
2 Flute Up Cut General Purpose Router Bit
Diameter
5/32 in (3.97 mm)
Cutting Edge
5/8 in (15.88 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2 in (50.8 mm)
Rotation
Right-Hand (RH)
Cutting Geometry
2 Flutes / Up Cut Spiral
Construction
Solid Carbide Tooling Category
Application
Solid Wood Routing,MDF Routing,Some Plastics,Slotting,Dadoing,Profiling
2-Flute Upcut Spiral
Router Bit
Upcut Spiral Router Bit
Designed to route grooves, profiles and pockets.
D=5/32 in3.97 mm Diameter
CE=5/8 in15.88 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2 in50.8 mm Overall Length
Upcut Spiral Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid Carbide2 FlutesRH UpcutSKU R52-22804
Choose a holder or collet for the 1/4 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide upcut spiral router bit is designed to route grooves, profiles and pockets. It is suitable for solid wood, wood composites and selected plastics.
The cutting section follows the programmed path or guide to form the required shape. Choose the entry method and depth of cut to suit the tool’s end geometry. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 0.1563 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Technical Specifications
Upcut Router Bit R52-22804
- Royce Ayr
- 2-Flute General-Purpose Upcut Spiral Router Bit
- R52-22804
- Solid Carbide CNC Router Tooling
- 0.1563 in / 5/32 in (3.97 mm)
- 0.625 in / 5/8 in (15.88 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.000 in / 2 in (50.8 mm)
- 2
- Upcut Spiral
- RH / Right Hand
- None
- Material Compatibility: Solid Wood, Wood Composites, MDF, Core Panels, and Compatible Plastics · Machine Interface: CNC Routers with Precision 1/4-Inch Collets · Construction: Solid-Carbide Substrate
- Designed for compatible CNC routers and industrial routing equipment using precision 1/4-inch collets or approved toolholding systems.
Best Fit Applications
Small-Diameter CNC Grooving
MDF Slot Cutting
Solid Wood Routing
Panel Component Machining
Detailed Cabinet Parts
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 0.1563 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm toolholding for the shank size 0.250" and right-hand spindle operation. Secure the workpiece against lift from the upcut action. Plastic suitability is conditional; confirm the exact grade and cutting conditions.
Improve Compact CNC Routing Performance
Royce Ayr R52-22804 is designed to route grooves, profiles and pockets. It is suitable for solid wood, wood composites and selected plastics.
The cutting section follows the programmed path or guide to form the required shape. Choose the entry method and depth of cut to suit the tool’s end geometry. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 0.1563 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
