Royce Ayr 2-Flute Straight Carbide Router Bit - 1/2" Dia x 1" Cut
2-Flute Straight
Router Bit
Solid-carbide right-hand straight-flute router bit designed for general-purpose machining in solid wood,softwood,MDF,core panels,and compatible plastics. Its 1/2-inch cutting diameter,1-inch cutting edge,1/2-inch shank,and 3-inch overall length support accurate routing,grooving,slotting,and dado production.
Main Product Description
The Royce Ayr 2-Flute Straight General-Purpose Router Bit R56-11814 is engineered for production routing in solid wood,softwood,MDF,core panels,and compatible plastics. Its 0.5000-inch cutting diameter and 1.000-inch cutting edge provide a balanced configuration for profiling,grooving,slotting,dado work,and cabinet-component machining.
The straight dual-flute geometry applies neutral axial force compared with upcut or downcut spirals,helping reduce workpiece lifting during controlled passes. A rigid 0.500-inch solid-carbide body supports parallel sidewall tracking and helps limit deflection when machining deeper channels.
The 3.000-inch overall length and right-hand rotation are suited to compatible CNC routers and industrial overhead shapers. Correct collet condition,tool projection,spindle speed,feed rate,and depth-per-pass are essential for maintaining concentricity,cutting quality,and service life.
Best Fit Applications
Product Highlights
Neutral Axial Geometry
Straight-flute cutting action minimizes upward or downward thrust compared with spiral geometries during controlled routing passes.
Rigid 1/2-Inch Core
The solid-carbide body helps control side deflection and supports accurate vertical tracking in slots,grooves,and dado channels.
Production Wear Resistance
Solid-carbide construction supports cutting-edge retention and thermal stability in demanding wood and panel-processing cycles.
Compatibility & Installation Notes
Confirm that the spindle,router,or overhead-shaper toolholder accepts an exact 1/2-inch (12.7 mm) shank. Inspect the collet and nut for wear or contamination,minimize unsupported tool projection,and verify runout before machining. Establish spindle speed,feed rate,and depth-per-pass according to the material,machine power,and workholding conditions.
Improve General-Purpose Routing Accuracy
The Royce Ayr 2-Flute Straight General-Purpose Router Bit R56-11814 provides a rigid solid-carbide solution for cabinet,furniture,panel,and architectural-millwork production. Its 1/2-inch diameter,1-inch cutting edge,1/2-inch shank,and 3-inch overall length support repeatable routing across a broad range of common shop materials.
Balanced two-flute cutting action and right-hand rotation help maintain clean sidewalls,controlled chip formation,and consistent dimensions when the tool is correctly held and operated within suitable machining parameters.
