Working geometry
Use the cutter for the final pass that establishes the finished edge.
Royce Ayr 3-Flute Upcut Low Helix Finisher - 1/2" Dia x 1-1/8" Cut
CA$180.90
In stock
SKU
R60-22507
Product Type
3-Flute Upcut Low Helix Finisher
Diameter
1/2 in (12.7 mm)
Cutting Edge
1-1/8 in (28.575 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3-1/2 in (88.9 mm)
Rotation
RH / Right Hand
Geometry
3-Flute Low Helix Upcut
Construction
Solid Carbide / HW
Application
Plastic Routing, Composite Routing, Solid-Wood Finish Passes, Upcut Chip Evacuation, CNC Production
3-Flute Upcut Low Helix
Finisher Router Bit
Upcut Low Helix Finisher
Designed to finish routed edges and contours.
D=1/2 in12.7 mm Diameter
CE=1-1/8 in28.575 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Upcut Low Helix Finisher
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
HW / Solid Carbide3 Flutes3-Flute Low Helix UpcutSKU R60-22507
Choose a holder or collet for the 1/2 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide low helix upcut finisher is designed to finish routed edges and contours. It is suitable for plastics, composites and solid wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/2 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Technical Specifications
Upcut Low Helix Finisher · R60-22507
- Royce Ayr
- 3-Flute Upcut Low Helix Finisher
- R60-22507
- Low Helix Finisher Upcut
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 1.125 in / 1-1/8 in (28.575 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.500 in / 3-1/2 in (88.9 mm)
- 3
- 3-Flute Low Helix Upcut
- RH / Right Hand
- Coating: None · Construction: HW / Solid Carbide · Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 3-1/2-inch overall length.
Best Fit Applications
Plastic Routing
Composite Routing
Solid-Wood Finish Passes
Upcut Chip Evacuation
CNC Production
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 1/2 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm toolholding for the shank size 0.500" and right-hand spindle operation. Secure the workpiece against lift from the upcut action. Confirm the exact plastic or composite and cutting conditions. Match the tool to the specific material grade and cutting conditions.
Controlled Upcut Finishing
Royce Ayr R60-22507 is designed to finish routed edges and contours. It is suitable for plastics, composites and solid wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/2 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
