Downcut Top-Edge Control
The downcut spiral directs cutting pressure toward the workpiece to help reduce upper-edge chipping in laminated and wood-composite materials.
Royce Ayr 2-Flute Downcut Spiral Router Bit 5/8" (15.88mm)
CA$999.99
Out of stock
SKU
R57-32237
Product Type
Solid Carbide Downcut Spiral Router Bit
Series
General Purpose Downcut Spiral / R57-222/322 Downcut Spiral 2 Flute
Cutting Diameter
5/8 in (15.88 mm)
Cutting Edge
1-5/8 in (41.28 mm)
Shank
5/8 in (15.88 mm)
Overall Length
3-1/2 in (88.9 mm)
Flutes
2
Rotation
Right-Hand (RH)
Coating
None
Machine
CNC Router
Application
Solid Wood,Wood Composites,Laminated Panels,Plywood,Selected Plastics
2-Flute
Downcut Spiral
Router Bit
Solid-carbide right-hand downcut spiral router bit designed for clean top-edge CNC routing in solid wood, wood composites, laminated panels, plywood, and selected plastics. Its 5/8-inch cutting diameter, 1-5/8-inch cutting edge, matching 5/8-inch shank, and 3-1/2-inch overall length support deeper dados, grooves, pockets, profiles, cabinet parts, casegoods components, and panel-processing work.
D=5/8 in15.88 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Sh=5/8 in15.88 mm Shank
OAL=3-1/2 in88.9 mm Overall Length
Downcut Spiral Router Bit
This production tool combines solid-carbide construction, two downcut spiral flutes, right-hand rotation, no coating, and a matching 5/8-inch shank for deeper routing where clean upper edges and stable toolholding are priorities.
Solid Carbide2 FlutesRH DowncutSKU R57-32237
Designed for compatible CNC routers using a precision 5/8-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-32237 is part of the General Purpose Downcut Spiral family and is built for CNC routing where clean top-edge quality and controlled surface finish are important. Its downcut geometry directs cutting pressure toward the workpiece, helping reduce upper-edge chipping during dados, grooves, pockets, profiles, and panel-feature machining.
The 5/8-inch cutting diameter and 1-5/8-inch cutting edge provide useful reach for deeper routing operations in cabinet parts, casegoods components, fixture parts, millwork details, plywood, and laminated or wood-composite panels. The matching 5/8-inch shank and 3-1/2-inch overall length require a correctly sized collet or toolholder and adequate machine clearance.
This uncoated solid-carbide tool uses two downcut spiral flutes and right-hand rotation. Supplier-listed suitability includes hardwood, softwood, particle board, fiberboard, laminate material, plywood, hard plastic, soft plastics, and an aluminum or non-ferrous notation; material suitability and cutting parameters must be confirmed before production. Correct runout, projection, RPM, feed rate, chipload, pass depth, workholding, and chip or dust evacuation remain essential.
Technical Specifications
Downcut Spiral Bit R57-32237
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-32237
- General Purpose Downcut Spiral / R57-222/322 Downcut Spiral 2 Flute
- Solid Carbide CNC Router Tooling
- 5/8 in (15.88 mm) / 0.6250 in
- 1-5/8 in (41.28 mm) / 1.625 in
- 5/8 in (15.88 mm) / 0.625 in
- 3-1/2 in (88.9 mm) / 3.500 in
- 2
- RH / Right-Hand
- Solid Carbide · Downcut Spiral · Uncoated
- Solid Wood, Wood Composites, Laminated Material, Plywood, and Selected Plastics
- CNC Routers with Compatible 5/8-Inch Collets or Toolholders and RH Rotation
Best Fit Applications
Solid Wood CNC Routing
Wood Composite Panels
Laminated Panel Dados
Cabinet & Casegoods Parts
Deeper Grooves & Pockets
Product Highlights
5/8-Inch Production Format
The matching cutting diameter and shank support compatible CNC router setups requiring a larger solid-carbide downcut tool.
1-5/8-Inch Cutting Reach
The verified cutting-edge length provides useful capacity for deeper dados, grooves, pockets, profiles, and panel-routing operations.
Compatibility & Installation Notes
Confirm that the spindle, collet, and toolholder accept an exact 5/8-inch (15.88 mm) shank, support right-hand rotation, and provide adequate clearance for the 3-1/2-inch overall length and required projection. Verify the programmed cutting depth against the 1-5/8-inch cutting edge. Inspect and clean the collet, minimize unsupported projection, verify runout, and match RPM, feed rate, chipload, pass depth, workholding, guarding, and chip or dust evacuation to the selected material. Confirm parameters before using the supplier-listed aluminum or non-ferrous notation.
Improve Deeper Downcut Routing
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-32237 provides an uncoated solid-carbide solution for clean top-edge CNC routing in solid wood, wood composites, laminated panels, plywood, and selected plastics.
Its 5/8-inch cutting diameter, 1-5/8-inch cutting edge, matching shank, two-flute downcut geometry, right-hand rotation, and 3-1/2-inch overall length support controlled production machining when correctly held and operated.
