Downcut Top-Surface Control
The downcut spiral directs cutting pressure toward the workpiece to help control upper-surface breakout in laminate, melamine, and wood-based panels.
Royce Ayr 2-Flute Downcut Spiral Router Bit 3/8" (9.53mm) – 1"
CA$97.55
In stock
SKU
R57-32222
Product Type
2-Flute Downcut Spiral Router Bit
Series
R57-222/322 Downcut Spiral 2 Flute
Cutting Diameter
3/8 in (9.53 mm)
Cutting Edge
1 in (25.4 mm)
Shank
3/8 in (9.53 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Geometry
Downcut Spiral
Construction
Solid Carbide
Application
Solid Wood,Wood Composites,Laminated Material,Melamine,Some Plastics
2-Flute
Downcut Spiral
Router Bit
Solid-carbide downcut spiral router bit designed for clean top-edge CNC routing in solid wood, wood composites, laminated materials, melamine, and selected plastics. Its 3/8-inch cutting diameter, 1-inch cutting edge, matching 3/8-inch shank, and 3-inch overall length support dados, grooves, profiles, panel routing, and production machining where visible-surface quality matters.
D=3/8 in9.53 mm Diameter
CE=1 in25.4 mm Cutting Edge
Sh=3/8 in9.53 mm Shank
OAL=3 in76.2 mm Overall Length
Downcut Spiral Router Bit
This production tool combines solid-carbide construction, two downcut spiral flutes, and a matching 3/8-inch shank for controlled routing where clean upper edges and stable cutting are priorities.
Solid Carbide2 FlutesDowncut SpiralSKU R57-32222
Designed for compatible CNC routers and routing machines using a precision 3/8-inch collet or approved toolholding assembly.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-32222 is designed for general-purpose routing where clean top-edge quality is important. Its downcut spiral geometry directs cutting pressure toward the workpiece, helping control top-surface breakout during dadoes, grooves, panel routing, trimming, and profile work.
The 3/8-inch cutting diameter, 1-inch cutting edge, matching 3/8-inch shank, and 3-inch overall length provide a balanced format for compatible CNC router and routing-machine setups. The tool is suited to solid wood, wood composites, laminated material, melamine, and selected plastics where controlled downcut action is preferred.
This solid-carbide tool uses two downcut spiral flutes. Rotation and coating are not specified by the supplied source and must be confirmed before ordering or programming. Correct collet condition, minimum practical projection, verified runout, suitable RPM, feed rate, depth-per-pass, workholding, and dust or chip evacuation are essential for maintaining surface quality and reliable tool life.
Technical Specifications
Downcut Spiral Bit R57-32222
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-32222
- R57-222/322 Downcut Spiral 2 Flute
- Solid Carbide CNC Router Tooling
- 3/8 in (9.53 mm)
- 1 in (25.4 mm)
- 3/8 in (9.53 mm)
- 3 in (76.2 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide · Downcut Spiral
- Solid Wood, Wood Composites, Laminated Material, Melamine, and Selected Plastics
- CNC Routers and Routing Machines with Compatible 3/8-Inch Collets or Toolholders
Best Fit Applications
Solid Wood CNC Routing
Wood Composite Machining
Laminated Panel Dados
Melamine Panel Routing
Grooves & Clean Profiles
Product Highlights
Balanced 3/8-Inch Format
The matching cutting diameter and shank suit compatible CNC router setups requiring a stable general-purpose downcut configuration.
Panel & Groove Routing
The 1-inch cutting edge supports dados, grooves, trimming, profiles, and panel-processing operations where top-edge quality matters.
Compatibility & Installation Notes
Confirm that the spindle, collet, and toolholder accept an exact 3/8-inch (9.53 mm) shank and provide adequate clearance for the 3-inch overall length and required projection. Rotation and coating are not specified by the supplied source, so verify those details before ordering, programming, or installation. Inspect and clean the collet, minimize unsupported projection, verify runout, and match spindle speed, feed rate, cut depth, workholding, guarding, and dust or chip evacuation to the selected material.
Improve Clean Top-Edge Routing
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-32222 provides a solid-carbide solution for clean top-edge routing in solid wood, wood composites, laminated material, melamine, and selected plastics.
Its 3/8-inch cutting diameter, 1-inch cutting edge, matching shank, two-flute downcut geometry, and 3-inch overall length support controlled production machining when correctly held and operated.
