Cleaner Top-Edge Control
The downcut spiral directs cutting pressure downward to help reduce top-surface chipping in laminated and wood-based materials.
Royce Ayr 2-Flute Downcut Spiral Router Bit 3/16" (4.76mm)
CA$35.40
In stock
SKU
R57-22209
Product Type
2-Flute Downcut Spiral Router Bit
Series
R57-222/322 Downcut Spiral 2 Flute
Diameter
3/16 in (4.76 mm)
Cutting Edge
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2-1/2 in (63.5 mm)
Flutes
2
Coating
None
Material
HW
Application
Solid Wood,Wood Composites,Laminated Materials,Some Plastics,Dados,Grooves,Clean Top-Edge Routing
2-Flute
Downcut Spiral
Router Bit
General-purpose solid-carbide downcut spiral router bit designed for clean top-edge routing in solid wood, wood composites, laminated materials, and selected plastics. Its 3/16-inch cutting diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length support detailed grooves, dados, profiles, and cabinet-component machining.
D=3/16 in4.76 mm Diameter
CE=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Downcut Spiral Router Bit
This compact production tool combines two downcut spiral flutes, HW solid-carbide construction, and a precision 1/4-inch shank for controlled small-diameter routing where top-surface edge quality matters.
HW / Solid Carbide2 FlutesDowncut SpiralSKU R57-22209
Designed for compatible routers and CNC routing systems using precision 1/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22209 is a general-purpose tool designed for clean top-edge cutting in wood and wood-based sheet goods. Its downcut spiral geometry directs cutting pressure toward the workpiece, helping reduce top-surface chipping during dados, grooves, profiles, and laminated-material details.
With a 0.1875-inch cutting diameter, 0.750-inch cutting edge, 0.250-inch shank, and 2.500-inch overall length, the tool is suited to cabinet shops, millwork operations, router-table work, and CNC applications requiring a controlled small-diameter downcut configuration.
Royce Ayr lists this series for solid wood, wood composites, laminated materials, and selected plastics. Correct collet condition, tool projection, spindle direction, RPM, feed rate, depth-per-pass, material support, and chip evacuation are essential for maintaining edge quality, dimensional accuracy, and service life.
Technical Specifications
Downcut Spiral Bit R57-22209
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-22209
- R57-222/322 Downcut Spiral 2 Flute
- HW / Solid Carbide CNC Router Tooling
- 0.1875 in / 3/16 in (4.76 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 2
- Not Specified by Supplied Source
- HW / Solid Carbide · Downcut Spiral · Uncoated
- Solid Wood, Wood Composites, Laminated Materials, and Selected Plastics
- Routers and CNC Routers with Precision 1/4-Inch Collets
Best Fit Applications
Clean Top-Edge Routing
Laminated Dados & Grooves
Wood Composite Machining
Cabinet & Millwork Routing
Selected Plastic Routing
Product Highlights
Compact 3/16-Inch Diameter
The small cutting diameter supports detailed grooves, profiles, and controlled routing where narrow feature sizes are required.
HW Carbide Construction
The solid-carbide cutting body supports rigidity, cutting-edge retention, and repeatable dimensions in compatible production applications.
Compatibility & Installation Notes
Confirm that the router, spindle, and toolholder accept an exact 1/4-inch (6.35 mm) shank and provide suitable clearance for the 3/16-inch cutting diameter. Inspect and clean the collet, collet nut, and tool shank, minimize unsupported projection, verify runout, and confirm spindle direction before machining. Establish RPM, feed rate, plunge method, and depth-per-pass for the selected wood, laminate, composite, or plastic material.
Improve Small-Diameter Top-Edge Quality
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22209 provides a compact HW solid-carbide solution for detailed routing in solid wood, wood composites, laminated materials, and selected plastics.
Its 3/16-inch diameter, 3/4-inch cutting edge, 1/4-inch shank, two downcut flutes, and 2-1/2-inch overall length support clean top-edge machining when correctly held and operated within suitable cutting parameters.
