Clean Top-Edge Downcut
The downcut spiral directs cutting action toward the workpiece to help protect the upper edge in laminated and wood-based materials.
Royce Ayr 2-Flute Downcut Spiral Router Bit 1/8" (3.175mm)
CA$32.95
In stock
SKU
R57-22200
Product Type
2-Flute Downcut Spiral Router Bit
Diameter
1/8 in (3.175 mm)
Cutting Edge Length
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2-1/2 in (63.5 mm)
Flutes
2
Cut Direction
Downcut Spiral
Construction
Solid Carbide
Application
Solid Wood,Wood Composites,Selected Plastics,Laminated Material,Dados,Grooves,Clean Top-Edge Routing
2-Flute
Downcut Spiral
Router Bit
Small-diameter solid-carbide downcut spiral router bit designed for clean top-edge routing in solid wood, wood composites, selected plastics, and laminated materials. Its 1/8-inch cutting diameter, 3/4-inch cutting edge length, 1/4-inch shank, and 2-1/2-inch overall length support detailed grooves, dados, profiles, and precision CNC routing.
D=1/8 in3.175 mm Diameter
CEL=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Downcut Spiral Router Bit
This compact production tool combines solid-carbide construction, two downcut spiral flutes, and a precision 1/4-inch shank for controlled routing where clean upper edges and small-feature machining are priorities.
Solid Carbide2 FlutesDowncut SpiralSKU R57-22200
Designed for compatible routers and CNC routers using a precision 1/4-inch collet or approved toolholding assembly.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22200 is designed for clean routing work in woodworking, cabinetmaking, millwork, and panel-processing environments. Its downcut geometry directs cutting action toward the workpiece, helping produce a cleaner top edge in dados, grooves, routed details, laminated stock, and wood-based panels.
The 1/8-inch cutting diameter and 3/4-inch cutting edge length provide a compact format for smaller routed details, narrow grooves, controlled profiles, and precision CNC machining. The 1/4-inch shank and 2-1/2-inch overall length support compatible router and CNC collet systems.
This solid-carbide tool uses two downcut spiral flutes. The supplied source does not specify rotation or coating, so those details should be confirmed before ordering or programming. Correct collet condition, minimum practical projection, verified runout, suitable RPM, feed rate, depth-per-pass, workholding, and dust or chip evacuation are essential for reliable performance.
Technical Specifications
Downcut Spiral Bit R57-22200
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-22200
- Not Specified by Supplied Source
- Solid Carbide Router Bit
- 1/8 in (3.175 mm)
- 3/4 in (19.05 mm)
- 1/4 in (6.35 mm)
- 2-1/2 in (63.5 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide · Downcut Spiral
- Solid Wood, Wood Composites, Selected Plastics, and Laminated Materials
- Routers or CNC Routers with Suitable 1/4-Inch Collets
Best Fit Applications
Small-Diameter CNC Routing
Dados & Narrow Grooves
Laminated Panel Routing
Solid Wood Detail Work
Cabinet & Millwork Machining
Product Highlights
Compact 1/8-Inch Cutter
The small cutting diameter and 3/4-inch cutting edge support narrow grooves, detailed profiles, and controlled routing paths.
Solid-Carbide Construction
The solid-carbide body supports rigidity, cutting-edge retention, and repeatable dimensions in compatible production applications.
Compatibility & Installation Notes
Confirm that the router, CNC spindle, collet, and toolholder accept an exact 1/4-inch (6.35 mm) shank and provide adequate clearance for the 2-1/2-inch overall length and required projection. The supplied source does not specify rotation or coating, so verify those details before ordering or programming. Inspect and clean the collet, minimize unsupported projection, verify runout, and match RPM, feed rate, depth-per-pass, workholding, and dust or chip evacuation to the selected material.
Improve Small-Diameter Top-Edge Routing
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22200 provides a solid-carbide solution for clean top-edge routing in solid wood, wood composites, selected plastics, and laminated materials.
Its 1/8-inch cutting diameter, 3/4-inch cutting edge length, 1/4-inch shank, two-flute downcut geometry, and 2-1/2-inch overall length support detailed production machining when correctly held and operated.
