Compression Face Control
The compression geometry combines upward and downward shearing action to help reduce chipping on both panel faces.
Royce Ayr 2-Flute Chipbreaker Compression Router Bit 5/8" (15.88mm)
CA$198.00
In stock
SKU
R60-11006
Product Type
2-Flute Chipbreaker Compression Router Bit
Series
R60-110 Chipbreaker Compression
Diameter
5/8 in (15.88 mm)
Cutting Edge
2-1/4 in (57.15 mm)
Upcut Length
0.990 in (25.15 mm)
Shank
5/8 in (15.88 mm)
Overall Length
5 in (127 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated Wood,Veneered Wood,Wood Composites,Plywood Core Applications,Cabinet &Casegoods CNC Routing
2-Flute
Chipbreaker Compression
Router Bit
Uncoated HW solid-carbide right-hand 2-flute chipbreaker compression router bit designed for CNC routing of laminated, veneered, plywood, and wood-composite panels where top and bottom edge quality are critical. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 0.715-inch upcut section, matching 1/2-inch shank, and 4-inch overall length suit cabinet, casegoods, nested-routing, and production panel-processing applications.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Upcut=0.715 in18.16 mm Upcut Length
OAL=4 in101.6 mm Overall Length
Chipbreaker Compression Bit
This production tool combines HW solid-carbide construction, two compression flutes, right-hand rotation, and chipbreaker geometry to support clean top and bottom panel faces while limiting plywood-core furring and tearout.
HW / Solid Carbide2 FlutesRH CompressionSKU R60-11006
Designed for compatible CNC routers using a precision 1/2-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 2-Flute Chipbreaker Compression Router Bit R60-11006 is designed for CNC routing of laminated or veneered wood and wood-composite materials. Its compression cutting geometry combines upward and downward shearing action to help reduce chipping on both panel faces, making it suitable where clean top and bottom edges are required.
The chipbreaker design helps limit furring and tearout in plywood cores while promoting controlled chip formation. The 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 0.715-inch upcut length, matching 1/2-inch shank, and 4-inch overall length provide a compact production format for cabinet parts, casegoods, nested-based routing, and panel processing.
This uncoated HW solid-carbide tool uses two flutes and right-hand rotation. Proper performance depends on matching the tool to the CNC router, collet condition, tool projection, material construction, panel thickness, cutting depth, feed speed, spindle RPM, hold-down method, and chip-extraction system. RPM/feed data and country of origin are not specified by the supplied source.
Technical Specifications
Chipbreaker Compression Bit R60-11006
- Royce Ayr
- 2-Flute Chipbreaker Compression Router Bit
- R60-11006
- Chipbreaker Compression
- Solid Carbide Tooling / Precision CNC Tooling
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.28 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 2
- RH / Right-Hand
- HW / Solid Carbide · Chipbreaker Compression · Uncoated
- Laminated Wood, Veneered Wood, Plywood, and Wood Composites
- CNC Router
Best Fit Applications
Laminated Panel Routing
Veneered Panel Machining
Plywood Core Tearout Control
Cabinet & Casegoods Production
Nested-Based Panel Processing
Product Highlights
Chipbreaker Core Performance
The chipbreaker design helps limit plywood-core furring and tearout while supporting controlled chip formation.
1/2-Inch Production Format
The 1/2-inch diameter and shank, 1-5/8-inch cutting edge, and 4-inch overall length suit production CNC panel work.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank and support right-hand rotation. Verify collet condition, runout, tool projection, available clearance, programmed depth, panel thickness, upcut engagement, feed speed, RPM, vacuum hold-down, spoilboard condition, guarding, and dust extraction before production. Compression tools must engage the material correctly so the transition between upcut and downcut sections remains within the panel thickness and produces the intended top-and-bottom edge quality.
Improve Panel Edge Quality
The Royce Ayr 2-Flute Chipbreaker Compression Router Bit R60-11006 provides an uncoated HW solid-carbide solution for CNC panel routing where clean top and bottom edges and controlled plywood-core machining matter.
Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 0.715-inch upcut section, matching shank, two-flute compression geometry, right-hand rotation, and 4-inch overall length support cabinet, casegoods, and nested-panel production when correctly held and operated.
