Working geometry
The rounded tip follows shaped toolpaths and leaves a curved surface at the bottom of the cut.
Royce Ayr 2-Flute Ballnose Solid Carbide Router Bit - 1/4" Diameter x 7/8" Cut
CA$49.70
In stock
SKU
R52-23405
Product Type
2 Flute Ballnose Solid Carbide Router Bit
Diameter
1/4 in (6.35 mm)
Cutting Edge
7/8 in (22.22 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2 1/2 in (63.5 mm)
Flute Type
Up Cut / Ballnose End
Construction
Solid Carbide Tooling Category
Application
3D Contouring,Deep Relief Carving,Sculpting,Sign Making
2-Flute Upcut Ballnose
Router Bit
Upcut Ballnose Router Bit
Designed to machine curved surfaces and contours.
D=1/4 in6.35 mm Diameter
CE=7/8 in22.22 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Upcut Ballnose Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid Carbide2 FlutesUpcut BallnoseSKU R52-23405
Choose a holder or collet for the 1/4 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide upcut ballnose router bit is designed to machine curved surfaces and contours. It is suitable for solid wood and wood composites.
The rounded tip follows shaped toolpaths and leaves a curved surface at the bottom of the cut. The toolpath and stepover determine the remaining scallop between passes. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/4 in cutting diameter and 7/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Technical Specifications
Upcut Ballnose R52-23405
- Royce Ayr
- 2-Flute Upcut Ballnose Router Bit
- R52-23405
- R52-234 Upcut Ballnose
- 0.2500 in / 1/4 in (6.35 mm)
- 0.875 in / 7/8 in (22.22 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 2
- Upcut Spiral
- HW / Solid Carbide
- None
- Material Compatibility: Solid Wood and Wood Composites · Machine Interface: CNC Routers and Precision Routing Systems with 1/4-Inch Collets
- Designed for compatible CNC routers and precision routing systems using an exact 1/4-inch (6.35 mm) collet or approved toolholder.
Best Fit Applications
3D Relief Carving
Contour Profiling
Decorative Wood Carving
Solid-Wood Machining
Wood-Composite Surfacing
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 1/4 in cutting diameter and 7/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm toolholding for the shank size 0.250" and right-hand spindle operation. Secure the workpiece against lift from the upcut action.
Improve Carving and Contour Accuracy
Royce Ayr R52-23405 is designed to machine curved surfaces and contours. It is suitable for solid wood and wood composites.
The rounded tip follows shaped toolpaths and leaves a curved surface at the bottom of the cut. The toolpath and stepover determine the remaining scallop between passes. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/4 in cutting diameter and 7/8 in cutting length define the working section of this version. Its 1/4 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
