Low-Helix Upcut Geometry
Carries chips upward from the cutting zone while providing controlled pocketing action in compatible plastics, composites, MDF, and solid wood.
Royce Ayr 1/4" Diameter x 7/8" Cut 2-Flute Low Helix Up-Cut Solid Carbide Router Bit
CA$999.99
In stock
SKU
R52-74020
Product Type
2 Flute Low Helix Up-Cut Router Bit
Diameter
1/4 in (6.35 mm)
Cutting Edge
7/8 in (22.23 mm)
Shank
1/4 in (6.35 mm)
Article Number
R52-74020
Rotation
Right-Hand (RH)
Application
CNC Production,Deep Slotting,Profile Routing
2-Flute Low-Helix Upcut
Pocketing Router Bit
Low-Helix Pocketing Bit
Solid-carbide low-helix upcut pocketing router bit designed for plastics, composites, MDF door components, and finish passes in solid wood. Its 1/4-inch cutting diameter, 7/8-inch cutting edge, 0.010-inch corner radius, 1/4-inch shank, and 2-1/2-inch overall length support controlled deeper pocketing with a smooth bottom transition.
D=1/4 in6.35 mm Diameter
CE=7/8 in22.225 mm Cutting Edge
R=0.010 in0.254 mm Corner Radius
OAL=2-1/2 in63.5 mm Overall Length
Low-Helix Pocketing Bit
This two-flute solid-carbide tool combines low-helix upcut geometry with radiused corners for controlled chip evacuation and smoother pocket-bottom finishing.
Solid Carbide2 Flutes0.010-Inch RadiusSKU R52-74020
Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding assembly with clearance for the 2-1/2-inch overall length.
Main Product Description
The Royce Ayr 2-Flute Low-Helix Upcut Pocketing Router Bit R52-74020 is developed for pocketing plastics and composites, MDF door components, and finish passes in solid wood. Its 0.2500-inch cutting diameter and 0.875-inch cutting edge provide added reach for deeper pockets, recessed features, and detail-routing operations.
The low-helix upcut flute form carries chips upward while maintaining controlled cutting action. A 0.010-inch corner radius creates a smooth transition at the bottom of the pocket and avoids the sharp internal corner produced by square-edge geometry.
The 0.250-inch shank and 2.500-inch overall length require a compatible precision collet or approved toolholder. Collet condition, runout, tool projection, spindle direction, spindle speed, feed rate, stepover, depth per pass, workholding, and chip extraction should be established for the material and machine.
Technical Specifications
Low-Helix Pocketing Bit R52-74020
- Royce Ayr
- 2-Flute Low-Helix Upcut Pocketing Router Bit
- R52-74020
- Low-Helix Upcut Pocketing
- Solid Carbide / HW
- 0.2500 in / 1/4 in (6.35 mm)
- 0.875 in / 7/8 in (22.225 mm)
- 0.010 in (0.254 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 2
- Upcut
- Rotation: RH / Right Hand · Coating: None · Material Compatibility: Plastics, Composites, MDF, and Solid-Wood Finish Passes · Machine Type: CNC Router
- Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding assembly with clearance for the 2-1/2-inch overall length.
Best Fit Applications
MDF Door Pocketing
Plastic Pocketing
Composite Routing
Solid-Wood Finish Passes
Deeper Radius-Bottom Pockets
Product Highlights
0.010-Inch Corner Radius
Radiused corners create a smoother pocket-bottom transition and eliminate the sharp internal corner produced by square-edge geometry.
Extended Pocketing Reach
The 7/8-inch cutting edge and 2-1/2-inch overall length provide added reach for deeper CNC pocketing and recessed-feature work.
Compatibility & Installation Notes
Confirm that the CNC spindle or router toolholder accepts an exact 1/4-inch (6.35 mm) shank and provides sufficient clearance for the 2-1/2-inch (63.5 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, stepover, depth per pass, workholding, and chip extraction according to the material, machine, and approved shop procedures.
Improve Deeper Pocket Finish
The Royce Ayr 2-Flute Low-Helix Upcut Pocketing Router Bit R52-74020 provides a solid-carbide solution for pocketing plastics, composites, and MDF door components, as well as finish passes in solid wood. Its 1/4-inch diameter and 7/8-inch cutting edge support controlled CNC material removal in deeper compact features.
Low-helix upcut geometry supports chip evacuation, while the 0.010-inch corner radius promotes a smooth pocket-bottom transition when the tool is correctly held and operated within suitable machining parameters.
