Downcut Finishing Direction
Downcut flute direction supports controlled finishing engagement in compatible plastics, composites, and solid wood.
Royce Ayr 2-Flute Straight Carbide Router Bit - 1/2" Diameter x 1" Cut
CA$107.20
In stock
SKU
R60-22310
Product Type
2 Flute Straight General Purpose Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
1 in (25.4 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Rotation
Right-Hand (RH)
Article Number
R60-22310
Application
Solid Wood,MDF,Slotting,Dadoing,Profiling
3-Flute Downcut Low Helix
Finisher Router Bit
Downcut Low Helix Finisher
Solid-carbide downcut low-helix finisher for routing plastics and composites and for finish passes in solid wood. Its 3/8-inch cutting diameter, 1-1/8-inch cutting edge, 3/8-inch shank, three-flute geometry, and 3-inch overall length provide a compact finishing format for compatible CNC routers.
D=3/8 in9.525 mm Diameter
CE=1-1/8 in28.575 mm Cutting Edge
Sh=3/8 in9.525 mm Shank
OAL=3 in76.2 mm Overall Length
Downcut Low Helix Finisher
This three-flute solid-carbide tool combines downcut flute direction with low-helix finishing geometry for controlled routing in plastics, composites, and solid-wood finishing applications.
Solid Carbide / HW3 FlutesDowncut Low HelixSKU R60-22310
Designed for compatible CNC routers using a precision 3/8-inch (9.525 mm) collet or approved toolholding system with sufficient clearance for the 3-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22310 belongs to Royce Ayr's 3-Flute Downcut Low Helix Finisher series. The manufacturer specifies this series for routing plastics and composites and for finish passes in solid wood.
Its downcut flute direction and low-helix geometry support controlled material engagement during finishing operations. The three-flute format is suited to compatible CNC routing when spindle speed, feed rate, and chip load are correctly matched.
The 0.3750-inch cutting diameter, 1.125-inch cutting edge, 0.375-inch shank, and 3.000-inch overall length require a compatible precision collet or approved toolholder. Before machining, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being processed.
Technical Specifications
Downcut Low Helix Finisher R60-22310
- Royce Ayr
- 3-Flute Downcut Low Helix Finisher Router Bit
- R60-22310
- 3-Flute Downcut Low Helix Finisher
- HW / Solid Carbide
- 0.3750 in / 3/8 in (9.525 mm)
- 1.125 in / 1-1/8 in (28.575 mm)
- 0.375 in / 3/8 in (9.525 mm)
- 3.000 in / 3 in (76.2 mm)
- 3
- Downcut Low Helix Finisher
- RH / Right Hand
- Coating: None · Construction: HW / Solid Carbide · Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 3/8-inch (9.525 mm) collet or approved toolholding system with sufficient clearance for the 3-inch overall length.
Best Fit Applications
Plastic Finishing
Composite Routing
Solid-Wood Finish Passes
Downcut Profile Machining
Compact CNC Finishing
Product Highlights
Low-Helix Geometry
Low-helix geometry is intended for finish-routing applications where controlled cutting action is required.
Compact 3/8-Inch Format
The 3/8-inch diameter and shank, 1-1/8-inch cutting edge, and 3-inch overall length suit compatible CNC systems.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 3/8-inch (9.525 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being machined.
Add Compact Downcut Finishing Capability
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22310 provides a solid-carbide solution for routing plastics and composites and for finish passes in solid wood.
Its 3/8-inch diameter and shank, 1-1/8-inch cutting edge, three-flute downcut low-helix geometry, and 3-inch overall length suit compatible CNC systems when the tool is correctly held and operated within appropriate machining parameters.
