Marathon Wear Barrier
The performance coating reduces frictional heat and helps preserve the solid-carbide cutting edge during abrasive panel processing.
Leitz 1/2" × 1-1/4" Solid Carbide Compression 2-Flute Marathon
CA$198.85
In stock
SKU
L130091608
Product Type
Solid Carbide Compression Router Bit
Product Series
Marathon High-Performance Premium Coating
Dimensions
1/2"Cutting Dia x 1-1/4"Cutting Length x 3"OAL
Flute Count
2-Flute (2Flt) Geometry
Cutting Material
Premium Micrograin Solid Carbide (SC)
Shear Geometry
Opposing dual-action up/down compression axial shear
Application
Nesting,sizing,and chip-free machining of double-faced veneered and laminated panels
Leitz Marathon
Compression Bit
Marathon Compression Bit
Premium solid micrograin carbide compression router bit engineered with the proprietary Marathon wear-resistant coating. Designed for heavy-duty nesting operations on automated CNC centers demanding clean surfaces on both panel faces.
1/2 x 1-1/4 inDiameter x Edge
MarathonCoating Series
Solid CarbideSubstrate
2 FluteConfiguration
Marathon Compression Bit
This solid carbide CNC router tool combines synchronized up-shear and down-shear cutting zones to direct machining forces toward the center of laminated sheet goods.
Solid CarbideMarathon Coated2 FluteSKU L130091608
Designed for CNC routers and nesting centers using a 1/2-inch collet or compatible heat-shrink toolholder.
Main Product Description
The Leitz Marathon Solid Carbide Compression Router Bit is built for industrial nested manufacturing. Featuring a 1/2-inch cutting diameter, 1-1/4-inch cutting-edge length, and 3-inch overall length, this two-flute tool uses opposing axial shear geometries to reduce delamination. Its up-shear tip and down-shear upper section direct chips toward the center of the board, helping suppress fraying on both top and bottom surfaces.
Constructed from premium ultra-micrograin tungsten carbide, the tool body is protected by the Leitz Marathon wear-resistant coating. This barrier helps reduce frictional heat and shields the cutting edge from abrasive binders and resins found in modern composite panels, supporting extended service life, reliable dimensional accuracy, and consistently clean profiles across long production runs.
Accelerate nesting productivity and reduce secondary sanding with the genuine Leitz Marathon Solid Carbide Compression Router Bit. Engineered for precision cabinetry fabrication and demanding industrial CNC routers, this 1/2 x 1-1/4 x 3-inch tool delivers clean finishes along both material faces across repeated production cycles.
Technical Specifications
Marathon Compression Bit
- Leitz
- Marathon Compression Bit
- L130091608
- Solid Carbide Router Bit
- Marathon Coating Technology
- 1/2 in
- 1-1/4 in
- 3 in
- 2 Flutes, Opposing Compression Shear
- Premium Micrograin Solid Carbide
- Marathon Extreme-Wear Coating
- ISO G2.5 Optimized for High-Speed Spindles
- Shank Diameter: 1/2 in Straight Cylinder
- Designed for CNC routers and nesting centers using a 1/2-inch collet or compatible heat-shrink toolholder.
Best Fit Applications
High-Speed CNC Nesting Operations
Double-Faced Melamine Particleboard
Fine Veneered Architectural Plywood
High-Pressure Laminate Panels
Cabinet and Drawer Component Fabrication
Product Highlights
Synchronized Up/Down Shear
Opposing helix zones direct cutting forces inward to limit splintering on delicate top and bottom decorative surfaces.
Dynamic Core Integrity
The micrograin carbide core limits deflection under aggressive feed loads and supports consistent dimensional tracking.
Compatibility & Installation Notes
Ensure the 1/2-inch shank is fully seated in a clean, correctly sized premium collet or compatible heat-shrink toolholder to limit radial runout. Confirm that the initial plunge depth fully engages the up-shear tip section before beginning a compression cut. Operate within the machine, material, and toolholder manufacturer's recommended RPM, feed-rate, chip-load, and maximum insertion specifications.
Accelerate Nesting Productivity
Accelerate nesting productivity and reduce secondary sanding with the genuine Leitz Marathon Solid Carbide Compression Router Bit. Engineered for precision cabinetry fabrication and demanding industrial CNC routers, this 1/2 x 1-1/4 x 3-inch tool delivers clean finishes along both material faces across repeated production cycles.
The combination of micrograin tungsten carbide and Marathon coating handles tough laminates and abrasive board cores while maintaining edge quality. Genuine L130091608 tooling provides the geometry, chip evacuation, and dimensional stability needed for premium cabinet and architectural millwork production.
