Flange Drive Pin Holes
Integrated pin holes provide positive engagement with compatible machine flanges to support reliable torque transfer under heavy panel-stack loads.
Leitz Premium 370mm Panel Saw Main Blade - 72-Tooth FZ/TR Triple Chip Carbide Beam Saw Blade
CA$196.20
Out of stock
SKU
L163416
Product Type
Industrial Carbide (HW) Beam Saw Main Blade
Product Series
Premium High-Capacity Panel Sizing Optimization
Dimensions
370mm Diameter x 4.4mm Kerf / 3.2mm Plate x 80mm Bore + Pin Holes (PH)
Tooth Count
72 Teeth (Z72)
Tooth Geometry
FZ/TR (Flat / Triple-Chip Ground Profile)
Cutting Material
Premium Micrograin Tungsten Carbide (HW)
Application
Heavy-duty industrial sizing and division of coated,laminated,and composite sheet boards
Leitz Premium
Main Saw Blade
Premium Main Saw
Industrial-grade main beam saw blade engineered with a heavy-duty 4.4 mm kerf and integrated pin-hole arrangement. Designed for stable, low-vibration panel division and high-volume finishing cuts on demanding panel-sizing lines.
370 x 4.4 mmDiameter x Kerf
80 mm + PHBore & Pin Holes
Z72 FZ/TRTeeth / Grind
Premium HWCarbide Grade
Premium Main Saw
This carbide-tipped main saw blade uses high-density micrograin inserts ground to an alternating flat/triple-chip profile for demanding beam-saw panel processing.
Premium HW Carbide4.4 mm Kerf80 mm + PHSKU L163416
Designed for compatible industrial panel and beam saw systems using a 370 mm blade diameter, 80 mm bore, and matching flange pin-hole pattern.
Main Product Description
The Leitz Premium HW Main Saw Blade is engineered for heavy-duty industrial panel processing. Built with a 370 mm outer diameter, 4.4 mm kerf, 3.2 mm plate-body thickness, and 80 mm bore with secondary pin holes for secure flange engagement, this 72-tooth main blade is designed to process abrasive sheet stacks under continuous production loads. Its FZ/TR flat/triple-chip geometry distributes cutting pressure across the tooth pattern to help reduce surface chipping and tear-out on double-sided coated boards.
The precision-tensioned alloy tool-steel plate is engineered to maintain flatness and limit axial runout at demanding feed rates. Premium micrograin tungsten-carbide tips use optimized clearance geometry to reduce friction and heat generation, supporting reliable dimensional accuracy and consistent cut quality during extended production cycles.
Optimize panel-dividing operations with the heavy-duty performance of the Leitz Premium HW Main Saw Blade. Designed for high-capacity beam-saw plants and architectural millwork production, this 370 x 4.4 x 80 mm blade delivers stable, straight tracking through abrasive laminate and multi-layer board structures.
Technical Specifications
Premium Main Saw L163416
- Leitz
- Premium Main Saw
- L163416
- Industrial Carbide (HW) Saw Blade
- Premium Panel Sizing Series
- 370 mm
- 4.4 mm
- 3.2 mm
- 80 mm
- Pin-Hole Pattern Layout (+PH)
- 72 Teeth (Z72)
- FZ/TR (Flat / Triple-Chip Ground)
- Tip Material: Premium Micrograin Tungsten Carbide (HW)
- Designed for compatible industrial panel and beam saw systems using a 370 mm blade diameter, 80 mm bore, and matching flange pin-hole pattern.
Best Fit Applications
Heavy Automated Panel Sizing Lines
Stacked High-Pressure Laminates
Double-Sided Melamine Panel Stacks
Abrasive High-Density Fiberboard
High-Volume Architectural Millwork
Product Highlights
Vibration-Controlled Core
Engineered expansion slots and a tensioned steel plate help reduce axial movement, vibration, and cutting noise.
Advanced FZ/TR Geometry
The trapezoidal tooth scores the cutting path while the flat tooth clears the center for clean edges on brittle decorative surfaces.
Compatibility & Installation Notes
Verify that the machine spindle matches the 80 mm bore and that the flange pins align precisely with the integrated pin-hole pattern before mounting. Align the blade rotation marking with the spindle direction, confirm flange cleanliness and runout, and use a correctly calibrated scoring system when processing coated single sheets or stacked composite panels.
Strengthen Main-Saw Performance
Optimize panel-dividing operations with the heavy-duty performance of the Leitz Premium HW Main Saw Blade. Designed for high-capacity beam-saw plants and architectural millwork production, this 370 x 4.4 x 80 mm blade delivers stable, straight tracking through abrasive laminate and multi-layer board structures.
The combination of micrograin tungsten-carbide tips, a precision-tensioned steel core, and positive flange pin engagement supports consistent cutting quality under demanding loads. Genuine L163416 tooling provides the structural stability, chip clearance, and balancing accuracy required for reliable industrial panel processing.
