Heavy-Duty 4.4 mm Kerf
The wider kerf profile supports stable tracking and helps limit deflection during multi-sheet panel-stack processing.
Leitz Premium Panel Saw Blade D360xb65xZ72 FZ/TR 4.4K
CA$336.70
In stock
SKU
L163415
Product Type
Industrial Carbide (HW) Panel Sizing Saw Blade
Product Series
Premium Beam &Panel Dividing Optimization
Dimensions
360mm Diameter x 4.4mm Kerf / 3.2mm Plate x 65mm Bore
Tooth Count
72 Teeth (Z72)
Tooth Geometry
FZ/TR (Flat / Triple-Chip Ground Profile)
Cutting Material
Premium High-Density Tungsten Carbide (HW)
Application
Heavy-duty industrial sizing and division of coated,laminated,and composite sheet boards
Leitz Premium
Panel Saw
Premium Panel Saw
Heavy-duty industrial panel-sizing circular saw blade with a 4.4 mm kerf and FZ/TR flat/triple-chip tooth geometry. Engineered for stable, low-vibration finishing cuts on automated panel-dividing systems and high-capacity beam saw lines.
360 x 4.4 mmDiameter x Kerf
65 mmBore Diameter
Z72 FZ/TRTeeth / Grind
Premium HWCarbide Class
Premium Panel Saw
This carbide-tipped panel-dividing blade uses high-density micrograin inserts and flat/triple-chip geometry to withstand demanding cutting loads while maintaining clean panel edges.
Premium HW Carbide4.4 mm KerfZ72 FZ/TRSKU L163415
Designed for compatible industrial panel saws and beam saws using a 360 mm blade diameter and 65 mm bore.
Main Product Description
The Leitz Premium HW Panel Sizing Circular Saw Blade is engineered for heavy-duty automated panel manufacturing. Built with a 360 mm outer diameter, 4.4 mm kerf, 3.2 mm plate-body thickness, and 65 mm bore, this 72-tooth main blade processes abrasive sheet stacks with stable, controlled cutting action. Its FZ/TR flat/triple-chip geometry helps divide material cleanly while reducing exit chipping on coated top and bottom surfaces.
The alloy tool-steel plate is tensioned to maintain flatness and resist thermal deformation under demanding industrial feed loads. Premium micrograin tungsten-carbide tips are selected to withstand abrasive wood resins, adhesives, and composite-panel binders, supporting longer intervals between sharpening cycles and consistent edge quality across extended production runs.
Optimize panel-dividing operations with the heavy-duty performance of the Leitz Premium HW Panel Saw Blade. Built for high-capacity sizing plants and architectural millwork production, this 360 x 4.4 x 65 mm blade delivers stable, straight tracking through abrasive laminate and multi-layer panel structures.
Technical Specifications
Premium Panel Saw L163415
- Leitz
- Premium Panel Saw
- L163415
- Industrial Carbide (HW) Saw Blade
- Premium Panel Sizing Series
- 360 mm
- 4.4 mm
- 3.2 mm
- 65 mm
- 72 Teeth (Z72)
- FZ/TR (Flat / Triple-Chip Ground)
- High-Tensile Tensioned Tool Steel
- Tip Material: Premium Micrograin Tungsten Carbide (HW)
- Designed for compatible industrial panel saws and beam saws using a 360 mm blade diameter and 65 mm bore.
Best Fit Applications
Automated Industrial Panel Dividing
Stacked High-Pressure Laminates
Double-Sided Melamine Panel Stacks
Abrasive High-Density Fiberboard
Architectural Millwork Panel Sizing
Product Highlights
Vibration-Controlled Plate
Engineered expansion slots and a tensioned steel body help reduce axial movement, vibration, and cutting noise.
Advanced FZ/TR Geometry
The trapezoidal tooth scores the cutting path while the flat tooth clears the center for clean edges on brittle decorative surfaces.
Compatibility & Installation Notes
Confirm that the machine spindle and clamping system match the 65 mm bore and can accommodate the 360 mm blade diameter and 4.4 mm kerf before installation. Align the rotation marking with the machine spindle direction, verify flange cleanliness and runout, and use the correct scoring setup when processing coated single sheets or stacked composite panels.
Strengthen Panel-Dividing Performance
Optimize panel-dividing operations with the heavy-duty performance of the Leitz Premium HW Panel Saw Blade. Built for high-capacity sizing plants and architectural millwork production, this 360 x 4.4 x 65 mm blade delivers stable, straight tracking through abrasive laminate and multi-layer panel structures.
The combination of micrograin tungsten-carbide tips and a tensioned steel core supports consistent cutting quality across demanding board materials. Genuine L163415 tooling provides the balancing tolerance, chip clearance, and structural stability required for reliable industrial panel processing.
