110 mm diameter · 63 mm flange · 65 mm overall length
Blade Range
Compatible circular saw blades from 200–350 mm diameter
Mounting Pattern
6 × M6x10 countersunk screws · 60° spacing · 90 mm pitch circle
Optional Accessory
Z092.100.N security flange for added stability and larger compatible blades
Klein · SISTEMI CNC Toolholding
HSK63F
Saw Blade Adapter
Circular Saw Blade Adapter
A Klein T128 adapter for mounting compatible circular saw blades with a 30 mm bore on HSK63F CNC machining centres. The exact T128.160.R Item provides a 40 mm projection dimension, 110 mm adapter diameter, 63 mm HSK flange diameter, and 65 mm overall length for compatible blades from 200 to 350 mm diameter.
HSK63FMachine Interface
40 mmProjection (A)
30 mmSaw Blade Bore (D1)
200–350 mmCompatible Blade Diameter
Tool Type
Circular Saw Blade Adapter
The T128.160.R is a non-cutting HSK63F adapter designed to carry compatible circular saw blades with a 30 mm bore. Six countersunk M6x10 screws are supplied for the official 60° mounting pattern on a 90 mm pitch circle.
HSK63F30 mm BoreA = 40 mmSKU T128.160.R
System Fit
For compatible CNC machining centres and circular saw blades from 200 to 350 mm diameter. The optional Z092.100.N security flange is recommended when greater stability and concentricity are required and is used for larger compatible blade diameters.
Main Product Description
Klein T128.160.R is the 40 mm projection HSK63F variant in the T128 family of circular saw blade adapters. The official Item row specifies a 40 mm A-dimension, 110 mm adapter diameter, 30 mm saw blade bore interface, 63 mm flange diameter, 2.5 mm blade-seat dimension, and 65 mm overall length.
The adapter is supplied with six M6x10 countersunk screws arranged at 60° on a 90 mm pitch circle for mounting compatible saw blades. The countersunk fixing arrangement allows flush-cutting work and supports compatible mitre and rafter-cutting operations when the machine, blade, guarding, and setup are suitable.
The standard adapter configuration is specified for saw blades from 200 to 350 mm diameter. Klein recommends the optional Z092.100.N security flange when improved stability and concentricity are needed and when the approved larger-diameter flange arrangement is required.
Machine / System FitFor compatible CNC machining centres and circular saw blades from 200 to 350 mm diameter. The optional Z092.100.N security flange is recommended when greater stability and concentricity are required and is used for larger compatible blade diameters.
Application Matrix
Best Fit Applications
HSK63F CNC Sawing Operations
Flush-Cutting Setups
Mitre-Cutting Operations
Rafter-Cutting Operations
200–350 mm Circular Saw Blades
Performance Details
Product Highlights
01
Compact 40 mm Projection
The T128.160.R uses the 40 mm A-dimension and a 65 mm overall length for compact HSK63F circular-saw mounting setups.
02
Six-Screw Countersunk Mounting
Six supplied M6x10 countersunk screws secure compatible 30 mm-bore saw blades on the official 60° pattern at a 90 mm pitch-circle distance.
03
Optional Precision Flange
The compatible Z092.100.N security flange improves stability and concentricity when greater precision or an approved larger-blade setup is required.
Before Machining
Compatibility & Installation Notes
Confirm the exact T128.160.R Item code, HSK63F spindle interface, 30 mm blade bore, saw blade diameter, blade mounting-hole pattern, adapter clearance, machine guarding, spindle direction, machine speed limits, and workholding before installation. The standard adapter is specified for 200–350 mm blades. Use the Z092.100.N security flange and its dedicated mounting arrangement where the approved larger-diameter setup or additional stability is required.
Production Outcome
Compact HSK63F Saw Blade Mounting
Klein T128.160.R combines an HSK63F interface, 40 mm projection, 30 mm saw blade bore, 110 mm adapter diameter, and 65 mm overall length for compatible CNC circular-saw operations.
Correct blade fit, mounting pattern, screw installation, spindle interface, guarding, clearance, machine limits, and optional flange selection are essential to safe, accurate production use.
